Name:Double Pressure For Steam Turbine
Performance range:
Power: 1.5-16MW
Inlet pressure: 1.6-3.43MPa
Inlet temperature: 300-435degree
Inlet Admission quantity: 2.4-217.8t/h
Inlet Steam quantity: up to 57.5kg/kw.h
Fill gas parameters pressure: 0.15-0.343
Fill gas parameters temperature: 124-150degree
Fill gas parameters Admission quantity: 1.8-16.8t/h
Steam consumption: up to 5.2kg/kw.h
Summary
There are a great deal of waste gas, water steam and waste heat in steel, cement, oil refining, and other industrial enterprises It is caused tremendous waste of energy and severe environmental pollution. Double pressure for steam turbine uses the industrial waste heat which from the emissions generated and different pressure and temperature of the steam to conduct electricity. It is a inevitable product about advanced technology and environmental.
Model | Power /(MW) | Inlet specification | Fill gas parameters | Steam consumption | Outlet pressure | Weight | Motor model | ||||
Pressure | Temperature | Steam quantity | Pressure | Temperature | Steam quantity | ||||||
BN1.5-1.6/0.15 | 1.5/1.2 | 1.6 | 300 | 9/7 | 0.15 | 150 | 2.2/1.8 | 5.2/5.1 | 0.0088 | 15 | QF-1.5-2 |
BN2.5-1.6/0.15 | 2.5/2 | 1.6 | 300 | 13.5/12 | 0.15 | 150 | 3.7/3 | 5.2/5.1 | 0.0095 | 16.1 | QF-2.5-2 |
BN3.6-1.6/0.15 | 3.6/2.8 | 1.6 | 300 | 18/14 | 0.15 | 150 | 5.1/4.2 | 5.15/5.1 | 0.009 | 16.8 | QF-3.6-2 |
BN4.5-2.46/0.15 | 4.5/3.6 | 2.46 | 385 | 21/17.2 | 0.15 | 150 | 2.7/2.41 | 4.5/4.45 | 0.008 | 16.8 | QF-4.5-2 |
BN4.5-3.43/0.12 | 4.5/3.6 | 3.43 | 435 | 20.5 | 0.12 | 124 | 3 | 4.4/4.35 | 0.006 | 19 | QF-4.5-2 |
BN7.5-1.6/0.15 | 7.5/6 | 1.6 | 300 | 35.3/27 | 0.15 | 150 | 10.5/9 | 4.52/4.5 | 0.006 | 46 | QF-7.5-2 |
BN7.5-3.43/0.15 | 7.5 | 3.43 | 435 | 28.2 | 0.15 | 140 | 8 | 3.6/3.6 | 0.005 | 46 | QF-7.5-2 |
BN16-3.43/0.343 | 16 | 3.43 | 435 | 57.5 | 0.343 | 136 | 15/16.8 | 3.6 | 0.007 | 59.5 | QF-18-2 |
