MKCS-850 Centrifuge sieve for wheat starch production line.
Application
Wheat/cassava/potato/sweet potato starch fiber separation centrifugal sieve.
Description
The centrifugal sieve is used to separate fiber (residue) in the cassava starch emulsion. It is widely used for cassava starch extraction in large and medium - sized starch production enterprises.
When the equipment running, the starch slurry enters the bottom of the sieve basket, and then under the effect of centrifugal force and gravity, the slurry goes a complex curve movement toward the bigger size direction, even rolling. In the process, the bigger impurities arrive the outer edge of the sieve basket, collecting in the slag collection chamber, whist the starch particle which size is smaller than the mesh fall into the starch powder collection chamber.
The machine has spray nozzle device both in the back and front of the sieve basket. By spraying washing water, the material move speed is accelerated whist the starch particles are easy to separate from the fiber slag.
Characteristics of the equipment
1. The equipment is made of stainless steel to prevent starch pollution;
2. The equipment surface is treated in a special process, beautiful and oil & dirt resistance;
3. The rotating sieve basket is corrected by the authority balancing accuracy to ensure that the equipment running smoothly;
4. Its mesh is manufactured by special plate, beautiful and durable;
5. The nozzle passes strict contrast test of pressure and flow;
6. The devices features big capacity, reasonable allocation of power, high starch extraction rate, easily installed.
Technical Specification
Model | MKCS500 | MKCS650 | MKCS850 | MKCS1000 |
Rotary speed r/min | 900~1100 | 900~1100 | 900~1100 | 900~1100 |
Screen basket diameter mm | 500 | 650 | 850 | 1000 |
Power kw | 11 | 15 | 18.5~37 | 45 |
Capacity(raw potato) t/h | 10 | 20 | 35 | >35 |
Material | SS304 | SS304 | SS304 | SS304 |
Weight kg | 1150 | 1300 | 1480 | 1800 |
Outside dimensions mm | 2300×850×1760 | 1785×1000×1905 | 1965×1200×2055 | 2075×1400×2205 |
Structure chart and equipment photos
