Virgin coconut oil,olive oil decanter centrifuge 3 phase oil separator
Tubular separator is one of our company produces the series products, mainly used in biological medicine, Chinese medicine, health food, beverage, chemical and other industries of the liquid - solid separation and liquid - liquid - solid three phase separation. Is the ideal equipment in the separated by centrifugation. The separation factor of tubular separator of 15900-16700, the minimum separation for 1 micron particles, so for some small proportion of liquid-solid phase difference, fine particle size, solid content is low, strong corrosive medium, such as material, concentration, was suitable for clarification in advance
High speed tubular separator has a slender high-speed rotating drum, material liquid from the bottom of the liquid into the hole,under the action of centrifugal force field, forcing the material liquid to flow up along the inner wall of the drum, and because of the density difference between the different components of material liquid and the radial stratification, supernatant of upper discharging mouth outflow, the sediment of deposition inside the drum to artificial root out.
Drum speed | 16000 r/min |
Max centrifugal force | 15050 R.C.F |
Drum inner diameter | φ105 mm |
Drum effective length | 742 mm |
Solid volume in drum | 6 L |
Stuff inlet pressure | <0.1Mpa |
Output (water flux) | 200~1200 L/h |
Motor power | 3 KW |
Specification | 760×450×1680 mm |
Stuff inlet diameter | φ12 mm |
Liquid outlet diameter | φ38 mm |
Liquid outlet height | 880~940 mm |
1. Professional experience and ability to accept orders.
2. Quick answer your inquiries, questions and emails in 6 hours.
3. Direct control on material, testing, quality, lead time ect.
4. Flexible Payment terms ranged at different quantity.
1. How long are your products warranty period?
We provide free service 12 months.
After that, you can still enjoy our service.
2. How does your factory do regarding quality control?
(1) We test the feed material in our lab especially fuel oil and waste oil etc.
(2) Raw material control.
(3) We trace the different phase of production from beginning, In particular key quality points(drum) control.
(4) Pilot operation.
(5) Track customers for a long time, improve products according to the problems and expectations raised by customers.
3. Can you supply all line products ?
Yes, we can, we have professional engineers to produce different lines.
Such as: coconut oil line production, sludge dehydrating line and waste oil recycling line, ect.
4. Can you provide the wearing parts?
Of course.
