Product Application
The centrifugal Spray Dryer is widely used technology in the liquid shaping technology and drying industry. It is suitable for producing powder, particle solid products from material of solution, emulsion, solidus and paste states. Therefore, when the particle size of the distribution final products, the residual water contents, the stocking density and the particles shape meet the precision standards, the centrifugal spray dryer is one of the most desired technologies.
Principle of work:
After filtering and heating, the air enter air distributor at the top of the dryer. The hot air enters the drying chamber in the spiral form uniformly. By passing through the high-speed centrifugal atomizer at the top of the tower, the material liquid will be rotated and sprayed into extremely fine mist liquid beads, through the very short time of contacting with hot air, the materials can be dried into the finished products. The finished products will be discharged continuously from the bottom of the drying tower and from cyclone separator. The waste gas emission by exhaust fan.
Outline:
1. Atomization: amomizing system must ensure a uniform distribution of the fog drops, which is crucial to ensure a good qualified rate of products.
2. Contact with hot airflow and fog drops: when enough hot air enters into drying tower, the direction and angle of hot air flaw have to be considerated, no matter cocurrent or mixed flow, must ensure the sufficient heat exchange, it is crucial.
3. The angle design of pipeline and cone. It is very important to select the suitable angle, here we would like to share our experience and data from production of thousands of this equipment.
Main Features
1) High Speed of Drying, after the spraying of the material liquid, the surface area of material will be increased greatly. In the hot air flow, 95-98% of water can be evaporated at the moment. The time of completing the drying needs only several seconds. It is especially suitable for drying thermolabile ingredients.
2) At final products own the good uniformity, mobility, and dissolving capacity. And the final products are high in purity and good in quality.
3) The production procedure is simple and the operation control easy. The liquid with the moisture contents 40-60% (for special mterials, the content may reach 90%) can be dried into powder or particle products at a time. After the drying, there is no need for smashing and sorting, so as to reduce the operation procedures in the production and chance the product purity. The product particles diam enters, looseness and water contents can be adjusted through changing the operation condition in a certain scope, it is very convenient to carry out the control management.
Machine Parts
Name: Observation window
Brand: Yuzhou
Original: China
The main tower adopts the quick-open cleaning door, the clean-up door adopts the integral design, and is optimized on the manhole design of the Danish Nile spray tower, and our company has applied for a new practical patent (patent number: 201320350821.9) Door operation is simple and convenient, while ensuring absolute sealing, to ensure that the manhole wall will not keep the material.
Main Features
Name: Inlet air spiral air distributor
Brand: Yuzhou
Original: China
Unique inlet air spiral air distributor, this device is our company’s patent (patent number: 201320354456.9), can guarantee on the circumference of the tower body, air volume down absolutely uniform, avoid wall material viscosity.
Machine Parts
Name: Sprial Rotating Discharge material
Brand: Yuzhou
Original: China
The material spiral rotating discharge by air volume, and generate negative pressure and siphon off the material which could properly prevent the congestion of powder.
Main Features
Name: Pneumatic hammer
Brand: Yuzhou
Original: China
In order to make the material dry powder stick in the inner wall straight and the cone adsorption, the cone added 4 pneumatic hammers, effectively prevented the inner wall product more phenomenon. Penumatic Hammer to prevent vibration of tower wall for a long time makes the tower wall cracking or deformation, we use the steel beam welding in the tower wall first, because of the steel beam is made of 6 mm steel plate production, able to withstand the impact of the larger, exciting force produced by the jar have passed to the tower wall girder, and shock control adopts the symmetry of excitation method, to avoid the shock generated when resonance phenomenon, very good to protect the walls, not easy to deformation and cracking phenomenon.
| Packaging | |
| Size | 123 (L) * 456 (W) * 789 (D) |
| Weight | 2.2 T |
| Packaging Details | According to each model dimension. Will pack with standard export wooden case, and I will notice the package size after placing an order. |
