wood biomass pellet mill / pellet machine equipment on sale
Professional Real Manufacturer for wood pellet mill!
We are specialized in designing and manufacturing biomass pellet machinery and the complete production line(all auxiliary equipment) with advanced technology abroad.
The current products include: hammer mill, ingredient weighing system, mixer, pellet mill, counter-flow cooler, dryer, crumbler, rotary screener, liquid adding equipment, pulse filter equipment, horizontal and vertical conveying equipment, links and gates, permanent magnet cylinder, and de-iron equipment etc.
Applications of Wood Pellet Production Line
It is mainly used for agro-forestry residues ,such as straw ,cotton stalk , rice husk ,peanut shell ,bamboo,empty fruit branch,pulverized coal and waste paper etc.
| Biomass materials |
| A, wood dust resources 40% wood dust will be produced when the wood is processed into other articles, wood utilization rate is only 60%. 1,Sawdust (75%) Dust and debris from sawmill. Size is usually 2 * 2 * 15 mm. Moisture content is usually 50-60%. |
| 2,Cut scraping dust (20%) From the fines after cutting and grinding Moisture content is usually 6-12%. |
| 3,Waste wood (5%) typical old wood e.g. : door window frame from used house after demolition. And wood offcut, irregular branches flaw-piece, etc Old wood usually have the moisture contents of 8-12% flaw-piece and wood offcut usually have the moisture contents of 30-50%. |
| B,Palm fruit slag resources Palm fruit slag resources is rich in Malaysia, southeast Asia, after refining the palm oil, the rest of the palm is fruit beam. Usually moisture content is about 60%. |
| C,Straw resources Straw is the Stem diameter of waste mostly after the crops harvest, The main is rice straw, wheat straw and corn straw. Moisture content will usually from around 50% dropped below 20% after natural piling up. |
| D,Other waste resources The waste from family life, mixed paper, plastic and textiles residue, called RDF (high density fuel) products. Some industrial wastes, burning waste, such as polypropylene piece, the artificial plastic bags, etc. |
Parameters of wood pellet mill:
| Model | MZLH420 | MZLH520 | MZLH680 | MZLH780 |
| Capacity(T/H) | 0.8-1.2 | 1.5-1.8 | 2-2.5 | 2.5-3.5 |
| Main motor power(kw) | 75/90 | 110/132 | 160/185 | 200/220 |
| Feeder power(kw) | 2.2 | 3 | 4 | 4 |
| Ring die dia(mm) | 420 | 520 | 680 | 780 |
| Pellets dia(mm) | 6-8 | 6-8 | 6-8 | 6-8 |
Detail Quotation Solutions for you, we need to know Information as Follows:
(1). What capacity would your prefer?
-----The Capacity Range of Wood Pellet Machine: 0.8-1T; 1.5-2T; 2-3T;3-4T.
(2).What is your raw material?
-----According to different raw material(such as hard wood,soft wood,straw,rice hust), capacity is different.
(3).What is your raw material size?
-----Best size for pressing high quality pellets is 3mm-5mm.
(4).What is the moisture of your raw material?
-----Better to be 10-15%.( If large than this, then we will recommend your Dryer Machine)
(5).Final Pellets Size?
-----We have Diameter for Pellets:6mm, 8mm, 10mm, 12mm, (Different Diameters for your Different Requirement.)
------Pellets Length: Adjustable20-50mm. (Normally our clients ask pellets length of 33mm, between 30-36mm)
WHO is ATS machine:
ATS machine is china top 5 famous brand feed machinery manufacturer and engaged in feed machine industry for 20years.We are not only doing quite well for china domestic market but also fantastic for overseas market. ATS machine certified by SGS , CE, ISO, GOST, along with a lot of patents. please take a look at of our factory scene:
ATS certification for Animal Feed Pellet Making Mill with 1-20tph Capacity for Sale
Customer Visit To ATS And Shipment
Famous International Brands cooperate with ATS machine for Animal Feed Pellet Making Mill with 1-20tph Capacity for Sale
FAQ
1. Q: Are you a trading company or a manufacturer?
A: We are a manufacturer, which has 20 years of experience in this industry.
2. Q: How can I get to your company?
A: You can get a flight to Shanghai Airport. We will go to pick you up. (About 3-4 hours by car)
You can get a flight to Nanjin Airport. We will go to pick you up. (About 1 hour by car)
3. Q: How long is your warranty time?
A: One year(Calculated from the equipment arrives the customer's side.). After this period we will support you when needed. You will be welcome to contact us with any problem may happened.
4. Q: Will you send engineers to install the plant?
A: Yes, but at an extra cost payable by the customer. Or you can get local contractors to do the commissioning and we send one supervising engineer.
5. Q: Do you have some foreign customers using your equipment?
A: Yes, we have.our company has established business relationships with customers from all over the world...
If you are interested in ATS machine, pls feel free to contact with us:
Contact person: Mr David
0086-13921060980
WHO is ATS machine:
ATS machine is china top 5 famous brand feed machinery manufacturer and engaged in feed machine industry for 20years.We are not only doing quite well for china domestic market but also fantastic for overseas market. ATS machine certified by SGS , CE, ISO, GOST, along with a lot of patents. please take a look at of our factory scene:
ATS certification
Famous International Brands cooperate with ATS machine
Clients cooperation with ATS machine
ATS HONORS AND SHIPMENTS with ATS machine
FAQ
1. Q: Are you a trading company or a manufacturer?
A: We are a manufacturer, which has 20 years of experience in this industry.
2. Q: How can I get to your company?
A: You can get a flight to Shanghai Airport. We will go to pick you up. (About 3-4 hours by car)
You can get a flight to Nanjin Airport. We will go to pick you up. (About 1 hour by car)
3. Q: How long is your warranty time?
A: One year(Calculated from the equipment arrives the customer's side.). After this period we will support you when needed. You will be welcome to contact us with any problem may happened.
4. Q: Will you send engineers to install the plant?
A: Yes, but at an extra cost payable by the customer. Or you can get local contractors to do the commissioning and we send one supervising engineer.
5. Q: Do you have some foreign customers using your equipment?
A: Yes, we have.our company has established business relationships with customers from all over the world...
If you are interested in ATS machine, pls feel free to contact with us:
Contact person: Mr David
0086-13921060980
