Lw250*1000n High Speed Oil Water Decanter Centrifuge Separator

Product & Featuresmain features &applicationsThe decanter centrifuge is suitable for solid-phase dewatering, liquid-phase clarification and separation, liquid-liquid-solid three phase separation and size-grading of various suspensions with solid-phas

Technical Feature

  • Dalian, China
  • 100 Sets/Year
  • L/C, T/T
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$60~7

PRIMARY PARAMETERS

Model NO.
LW250*1000N
Separation Mode
Sedimentation Type
Installation
Vertical
Pressure
Low Pressure
Bowl Diameter
250mm
Max Rotating Speed
5400
Processing Capacity
0.5-5m3/H
Weight
1000kg
Warranty
1 Year
Transport Package
Standard Wooden Case Package
Origin
Liaoning, China
Type
Centrifuge
Operating Type
Continuous Type
Centrifuge Type
Horizontal Spiral Centrifuge
Condition
New
Bowl Length
1000mm
Max Max Separation Factor
4080
Power(W)
7.5kw
Material
SS304,316L
Trademark
LW250*1000N Decanter Centrifuge
Specification
2410*800*1080 mm

DETAIL DESCRIPTION

Product & Features

main features &applications

The decanter centrifuge is suitable for solid-phase dewatering, liquid-phase clarification and separation, liquid-liquid-solid three phase separation and size-grading of various suspensions with solid-phase particle sizes of 0.005-15mm, consistency of 1-40% and temperature of ≤ 100°C, esp. for separatong the suspensions whose consistency and particle size vary greatly and for which recovery of filter cloth is difficult, such as treatment of PVC resins, ammonium sulfite, barrium carbonate, strontium sulphate, lithopone,starch, diatomite, plaster, bauxite, soybean protein, peanut protein, fruit juice, drinks, vegetable oil, citric acid, powder of blood, powder of titanium white, kaolin clay and drilling mud, etc., and dewatering of washed coal and fine coal, purification of waste oil, treatment of grain stillage liquid waste and municipal sewage and mineral classification. Besides, it is suitable for waste water treatment of electric power plant sludge, printing and dyeing sludge, paper manufacture sludge.



Schematic diagram

The solid drum is internally installed with a concentric discharge screw As they rotate in the same dJreotion at a high speed, They have a certain rotational speed difference, which is caused by the driving system and the differential case Suspension enters the internal of the charge screw through the speed pipe and then goes into the drum after being accele rated Under the centrifugal force, solid particles of big density settle on the inwall of the drun, and form a circular layer of cake, which is continuously pushed by the discharge screw to the small end of the drum 8nd then out of it, while the set:led liquid is continuously discharge out of the drum from the vortex finder of the big end of the drum, hence solid-liquid sparation of suspension.

For the decanter centrifuge, the continuous feeding separating and discharging can be realized as it rotates at its full speed. It is characterized by compact structure easy obturation smith running, low noises, large handing capacity, low energy consumption, high automation small working strength, simple operation and easy maintenance and wide application.

Lw250*1000n High Speed Oil Water Decanter Centrifuge Separator






Technical parameters


Lw250*1000n High Speed Oil Water Decanter Centrifuge Separator




Packaging & Shipping

Packaging:Standard Exported Wooden Case & Shipping:FOB & CIF & CNF & DDU etc.

Lw250*1000n High Speed Oil Water Decanter Centrifuge Separator



Company show


Liaoyang Zhonglian Pharmaceutical Machinery Co.,Ltd. ,belongs to ZHONGLINAN international Group. We are the professional manufacturer of pharmaceutical equipment and food equipment, which including separating equipment, filling equipment, packing equipment, dryer and relevant complete set of production line equipment.

Group was founded in 2001, the headquarters is located in Liaoyang city, Liaoning province. The factory covers an area of ten thousand square meters, production workshop seven thousand square meters. The factory own a professional r&d team and after-sales service team. In the same industry take the lead through the ISO9001:2008 international quality system certification, and get the certification of SGS, CE, GMP and so on.

At present, our products have been exported to the United States, Mexico, New Zealand, South Korea, Australia,Turkey,Japan,Thailand, Malaysia, Singapore,Indonesia,Canada,Kenya,Seychelles,Italy,Iran,Venezuela,Peru,India,Russia,Denmark,Spain,Finland,Greece,Colombia,and so on more than 30 countries. Our aim is saving your valuable time and cost, providing you with the workable solution!



Lw250*1000n High Speed Oil Water Decanter Centrifuge Separator



Our best service


Lw250*1000n High Speed Oil Water Decanter Centrifuge Separator



FAQ


Q1:Where can I get product&price information?
A1:Send us inquiry or email directly,we will contact you as we receive it.

Q2:How can I make sure your machinery is suitable for me?
A2:Please tell us all the separation information you know,such as your raw liquid,
two-phase or three-phase separation,solid content in liquid,solid size,the purpose,etc.
After analyzing your information,we will help you to choose a suitable model.
Then we could send the details and videos to you.

Q3:What should I do if I want to see the separation effect?
A3:We provide test service,you could come to our factory and take the raw liquid.
Or you deliver the raw liquid to us,we will do a test and record the process for videos.

Q4:How to enjoy the OEM services?
A4:As manufacturer for machinery,if you have some specific requirement,
we can produce as you required,such as the cover device,drum size,motor voltage,etc.

How to place the order

S1:You send us inquiry or email for your need
S2:According to your need,we choose the most suitable model for you
S3:We discuss the details and specific requirement
S4:You place an order and pay us 50% deposit
S5:We start to make the product
S6:When the machinery is done,we make photos for your check
S7:If there has no problem,you pay the balance
S8:We deliver the product to Chinese seaport or your country

Contact us
we are the leading manufacturer in pharmaceutical machinery, centrifugal separator and packaging machine. We know how to design and manufacture reliable, durable and lasting machine for you.
We treasure our reputation more than anything. We fulfill each promise. We offer the best we can. We want in return is your satisfaction, your acceptance and -- the friendship.

We are 400 km from Dalian Port, convenient and time-saving for shipping goods. We are 120km from Shenyang Taoxian International Airport, convenient for you to visit us.
