Fruit Juice Centrifuge Separator (DHC214/400/500)

Basic Principles of decanter centrifugeThe solid drum is internally installed with a concentric discharge screw As they rotate in the same direction at a high speed, They have a certain rotational speed difference, which is caused by the driving s

Technical Feature

  • Dalian, China
  • 30sets/Month
  • L/C, T/T
  • Centrifuge
  • Sedimentation Type
  • Continuous Type
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$0~29

PRIMARY PARAMETERS

Model NO.
DHC214/400/500
Condition
New
Silver
Stain Steel
Trademark
Hongji
Transport Package
Woode Case
Specification
SGS, CE
Origin
Liaoyang China

DETAIL DESCRIPTION


Basic Principles of decanter centrifuge
The solid drum is internally installed with a concentric discharge screw As they rotate in the same direction at a high speed, They have a certain rotational speed difference, which is caused by the driving system and the differential case Suspension enters the internal of the charge screw through the speed pipe and then goes into the drum after being accede rated Under the centrifugal force, solid particles of big density settle on the inwall of the drum, and form a circular layer of cake, which is continuously pushed by the discharge screw to the small end of the drum and then out of it, while the settled liquid is continuously discharge out of the drum from the vortex finder of the big end of the drum, hence solid-liquid separation of suspension.
Fruit Juice Centrifuge Separator (DHC214/400/500)

Characteristic of decanter centrifuge
For the decanter centrifuge, the continuous feeding separating and discharging can be realized as it rotates at its full speed. It is characterized by compact structure easy operation, smith running, low noises, large handing capacity, low energy consumption, high automation small working strength, simple operation and easy maintenance and wide application.


Application scope of decanter centrifuge
The decanter centrifuge is suitable for solid-phase dewatering, liquid-phase clarification and separation, liquid-liquid-solid three phase separation and size-grading of various suspensions with solid-phase particle sizes of 0.005-15mm, consistency of 1-40% and temperature of ≤ 100°C, esp. for separating the suspensions whose consistency and particle size vary greatly and for which recovery of filter cloth is difficult, such as treatment of PVC resins, ammonium sulfite, barium carbonate, strontium sulphate, lithopone, starch, diatomite, plaster, bauxite, soybean protein, peanut protein, fruit juice, drinks, vegetable oil, citric acid, powder of blood, powder of titanium white, kaolin clay and drilling mud, etc., and dewatering of washed coal and fine coal, purification of waste oil, treatment of grain stillage liquid waste and municipal sewage and mineral classification. Besides, it is suitable for waste water treatment of electric power plant sludge, printing and dyeing sludge, paper manufacture sludge.
 Fruit Juice Centrifuge Separator (DHC214/400/500)
 Main technical data:

Mode

Roller diameter
( mm)

Diameter ratio

The speed of the roller (r/min)

separation factor

Motor power
(kw)

weight
(kg)

LW220*660

220

3

4800

2840

7.5-11

900

LW220*880

220

4

4300

2280

7.5-11

1000

LW300*900

300

3

3750

2370

11-15

1300

LW300*1140

300

3.8

3750

2370

11-15

1500

LW350*1050

350

3

3700

2690

15

1700

LW350*1420

355

3.8

3700

2690

15-18.5

2000

LW400*1200

400

3

3500

2750

18.5-22

2500

LW400*1600

400

4

3200

2300

22-30

2800

LW450*1440

450

3.2

3000

2270

22-30

3200

LW500*1600

500

3.2

2800

2200

30-37

4000

LW500*2000

500

4

2800

2200

45-55

4800

LW530*2000

530

3.8

2700

2170

45-55

5200

FAQ
1.Is your price competitive?

My price is not the lowest in China as for high quality,but we promise for the same quality and collocation,my price is the most favorite,for the same price ,my quality is definitely superior.to other brand.

2.Do you have OEM service?Do you supply the parts?

Yes,we do,as long as you provide us your drawing and detailed requirements.

3.Do you have agent or service center in my country?

We have some partnership in several countries as Indonesia,Brazil,USA etc,you are warmly welcomed to work as our agent,at this moment,we have no service centers abroad,but we can provide overseas spot and online technical service in time.

4.How can we easily find out the most fit centrifuges?

We have experienced engineer team to help you make the model selection,as long as you provide us the detailed processing material characteristics.

5.What payment mode you accept?

  TT , LC at sight or others .

Note: The prodcution capacity is based on water only, just for reference. Different feeding solution will of different production capacity.
