Company Info.
A. Founded in 1992, a professinonal high-tech group speciallized in research, development and manufacturing of ultra-filtration (UF)water purification equipments and systems;
B. 2 UF membrane production sites in Haikou and Suzhou;
C. Patented UF membrane technology and UF products;
D. Widely application range: Municipal water supply / rural water quality improvement / industrial processing water supply / municipal sewage treatment and recycling / industrial waste water recycling / seawater desalination, etc.
E. Exported worldwidely and has established subsidiaries in North America, Europe (Turkey and Netherland)
Features of RF PVC
Litree Reinforced (RF) PVC UF module
A. High and stable flux - less investment cost
B. Unique module structure and efficient aeration - no sludge accumulation & lower operation cost
C. Strong tensile strength and excellent chemical resistance - longer service life
D. 0.02um filtration presicion - effectively remove suspended solids (SS) and microorganism
A. Founded in 1992, a professinonal high-tech group speciallized in research, development and manufacturing of ultra-filtration (UF)water purification equipments and systems;
B. 2 UF membrane production sites in Haikou and Suzhou;
C. Patented UF membrane technology and UF products;
D. Widely application range: Municipal water supply / rural water quality improvement / industrial processing water supply / municipal sewage treatment and recycling / industrial waste water recycling / seawater desalination, etc.
E. Exported worldwidely and has established subsidiaries in North America, Europe (Turkey and Netherland)
Features of RF PVC
Litree Reinforced (RF) PVC UF module
A. High and stable flux - less investment cost
B. Unique module structure and efficient aeration - no sludge accumulation & lower operation cost
C. Strong tensile strength and excellent chemical resistance - longer service life
D. 0.02um filtration presicion - effectively remove suspended solids (SS) and microorganism
| Types | GEMINI-2000-RF | GEMINI-1500-RF | GEMINI-950-RF |
| Membrane Material | Reinforced PVC | ||
| Fiber ID/OD(mm) | 1.0/2.0 | ||
| Active Membrane Area (m2) | 31 | 23 | 14 |
| Nominal Pore Size(μm) | 0.02 | ||
| Filtration Model | Outside-in | ||
| System Structure | Immersed | ||
| Max. Suction Pressure(-kPa) | 60 | ||
| Max. Operation Temperature (°C) | 40 | ||
| PH Range | 1~13 | ||
| Water Collector Material | ABS | ||
| Dimension L×W×H (mm) | 721×70×2122 | 721×70×1622 | 721×70×1082 |
| Weight(dry)kg | 16 | 13 | 9 |
