G Exhaust Gas Cycling Airstream Dryer
Description
FG airstream drying machine is newly developed with exhaust gas circulation function. It is divided into two steps to complete wet materials drying. Compared with other air stream drying equipments, this dryer can save 20% to 48% energy.
Application
FG airstream drying machine is used for drying non-viscous and loose materials, including starch, glucose, fish meal, sugar, draff, feed, gluten, plastic resin, coal dust and dye. Our air stream drying equipment can be extensively applied to dry powdery and granular materials in food, chemical, pharmaceutical, building materials and other industries.
Features
Compared with other air steam dryers, this airstream drying machine can save 30% energy due to its tail gas recycling. Therefore, this FG air stream drying equipment is characterized by high efficiency, fast speed, energy conservation and small space occupation.
Parameters
Description
FG airstream drying machine is newly developed with exhaust gas circulation function. It is divided into two steps to complete wet materials drying. Compared with other air stream drying equipments, this dryer can save 20% to 48% energy.
Application
FG airstream drying machine is used for drying non-viscous and loose materials, including starch, glucose, fish meal, sugar, draff, feed, gluten, plastic resin, coal dust and dye. Our air stream drying equipment can be extensively applied to dry powdery and granular materials in food, chemical, pharmaceutical, building materials and other industries.
Features
Compared with other air steam dryers, this airstream drying machine can save 30% energy due to its tail gas recycling. Therefore, this FG air stream drying equipment is characterized by high efficiency, fast speed, energy conservation and small space occupation.
Parameters
| Model | Evaporation of Water (kg/h) | Installed Powder (kw) | Floor Space (m2) | Heat Efficiency (%) |
| FG0.25 | 113 | 11 | 3.5 × 3.5 | >70 |
| FG0.5 | 225 | 18.5 | 7 × 5 | >70 |
| FG0.9 | 450 | 30 | 7 × 6.5 | >70 |
| FG1.5 | 675 | 55 | 8 × 7 | >70 |
| FG2.0 | 900 | 75 | 11 × 7 | >70 |
| FG2.5 | 1125 | 90 | 12 × 8 | >70 |
| FG3.0 | 1250 | 110 | 14 × 10 | >70 |
| FG3.5 | 1500 | 110 | 14 × 10 | >70 |
