50 Gpm Water Softener Equipment
Application scope of softener
Mainly used in industry and civil water softening preparation, such as Boiler feed water make-up water, air conditioning system make up water, heat exchanger, power plant, chemical, textile, printing and dyeing, bio-pharmaceutical, Electronic system and water pretreatment.
Control mode of fully automatic water softener
(1) Single tank time type: It adopts microcomputer to control the time, when operation of the equipment reaches setting time, it will automatically enter the regeneration condition, which can be regenerated for once a day or once for some day.
(2) Single tank flow type: It adopts control of turbine flow or electronic flow sensor, when the yield of softener reaches preset flow it will automatically enter the regeneration condition, which can be recycled many times every day.
(3) Double tanks flow type: Which could be divided into one running-one alternating, and simultaneous running and separately regeneration.
(4) One running and the other alternation type: One tank is running while the other is alternating, when water yield of operating tank reaches the preset flow rate, it will enter the regeneration stage, meanwhile, the other tank will enter the working state, these two tanks work and regenerate alternatively to realize continuous water supplying of 24 hours.
(5) Simultaneous running and separately regeneration type: Two cans running simultaneously, when the flow rate reaches the setting rate, one tank (can) will regenerate and the other tank will output water continuously, when the first regeneration tank finish the regeneration it will enter the working stage, the other one will enter regeneration stage, these two cans finish regeneration and enter working state simultaneously.
The Trouble With Hard Water
Hard water (calcium & magnesium) is a common problem for many
homeowners and businesses. When hardness minerals are combined with
heat it forms troublesome scale. Scale causes costly build-up in your
plumbing, water heater and other water using appliances. When combined
with soap, the minerals form soap curd or scum that makes skin dry and
itchy, hair lifeless, laundry dull and builds up on fixtures.
Benefit From Softer Water:
Silky shiny hair
Soft supple skin
Crystal clear dishes & glassware
Bright whites, vibrant colours
Easier cleaning
Use up to 75% less soap
Lower water heating cost by 29%
Protect plumbing & appliances
Extend life of laundry
| Hardness of raw water | ≤8mmol/L | Power supply | 220V/50HZ |
| Hardness of effluent | ≤0.03mmol/L | Control mode | flow rate type, time type |
| Inlet water pressure | 0.2~0.4Mpa | Resin | 001×7 strong acidic cation-exchange |
Free chlorine | ≤0.3mg/L | Working ambient temperature | 5-5degree |
| Suspended solid | <0.5mg/L | System water temperature | 5-4degree |
Iron content | <0.3mg/L | Relative humidity | ≤95%(25degree) |
| Type | Model | Water Output (m³/hour) | Resin-tank (diameter*Height) | Brine-tank(Liter) | Resin (kg) |
| Single Valve Single Tank | YL-I-0.5 | 0.5 | 200×900×1PC | 60×1PC | 20 |
| YL-I-1 | 1 | 250×1400×1PC | 60×1PC | 40 | |
| YL-I-2 | 2 | 300×1400×1PC | 100×1PC | 60 | |
| YL-I-3 | 3 | 350×1400×1PC | 130×1PC | 80 | |
| YL-I-4 | 4 | 400×1650×1PC | 200×1PC | 120 | |
| YL-I-5 | 5 | 500×1750×1PC | 300×1PC | 180 | |
| YL-I-6 | 6 | 600×1900×1PC | 350×1PC | 240 | |
| YL-I-10 | 10 | 750×1900×1PC | 500×1PC | 360 | |
| YL-I-18 | 18 | 900×1900×1PC | 800×1PC | 520 | |
| YL-I-25 | 25 | 1000×2200×1PC | 1000×1PC | 720 | |
| YL-I-35 | 35 | 1200×2400×1PC | 1500×1PC | 1000 | |
| YL-I-50 | 50 | 1500×2500×1PC | 2000×1PC | 1600 | |
| Dual Valve Dual Tank (Simultaneous working, alternate regeneration) | YL-II-36 | 36 | 900×1900×2PCS | 800×2PCS | 1040 |
| YL-II-50 | 50 | 1000×2200×2PCS | 1000×2PCS | 1440 | |
| YL-II-70 | 70 | 1200×2400×2PCS | 1500×2PCS | 2000 | |
| YL-II-100 | 100 | 1500×2500×1PCS | 2000×2PCS | 3200 | |
| Dual Valve Dual Tank (One work, one standby) | YL-II -1 | 1 | 250×1400×2PCS | 60×2PCS | 80 |
| YL-II-2 | 2 | 300×1400×2PCS | 100×2PCS | 120 | |
| YL-II-3 | 3 | 350×1400×2PCS | 130×2PCS | 160 | |
| YL-II-4 | 4 | 400×1650×2PCS | 200×2PCS | 240 | |
| YL-II-5 | 5 | 500×1750×2PCS | 300×2PCS | 360 | |
| YL-II-6 | 6 | 600×1900×2PCS | 350×2PCS | 480 | |
| YL-II-10 | 10 | 750×1900×2PCS | 500×2PCS | 720 | |
| YL-II-18 | 18 | 900×1900×2PCS | 800×2PCS | 1040 | |
| YL-II-25 | 25 | 1000×2200×2PCS | 1000×2PCS | 1440 | |
| YL-II-35 | 35 | 1200×2400×2PCS | 1500×2PCS | 2000 | |
| YL-II-50 | 50 | 1500×2500×2PCS | 2000×2PCS | 3200 |
