SCR30PM SERIES
Features:
1.Ally-win air end from Germany, the most advanced air end in the world.
2.Italian famous brand main motor, original imported key components
3.Low Energy Consumption,Low running,maintenance cost.
4.Aptitude and intelligent Control, integrated touch-screen PLC displayer.
5.Unique safe units make whole compressor more safety, more stable,lest noise,lest energy Loss.
6.Easy to install,operate,maintain.
TECHNICAL PARAMETER(SCR30PM Series)
Features:
1.Ally-win air end from Germany, the most advanced air end in the world.
2.Italian famous brand main motor, original imported key components
3.Low Energy Consumption,Low running,maintenance cost.
4.Aptitude and intelligent Control, integrated touch-screen PLC displayer.
5.Unique safe units make whole compressor more safety, more stable,lest noise,lest energy Loss.
6.Easy to install,operate,maintain.
TECHNICAL PARAMETER(SCR30PM Series)
| Model | SCR30PM-7 | SCR30PM-8 | SCR30PM-10 | |
| Capacity/Pressure (m3/min.Mpa-1) | 3.7/0.7 | 3.6/0.8 | 3.2/1.0 | |
| Motor | Power(KW) | 22KW(30H.P) | ||
| Speed(r/min) | 3000 | |||
| Starting way | Inverter Type | |||
| Volt(V) | 380 | |||
| Motor safety grade | IP65 | |||
| Motor isolation grade | F | |||
| Electrical Supply | 380V/50Hz/3Phase | |||
| Frequency Range | 75HZ-300HZ | |||
| Outlet Temperature(ºC) | ≤ Environment Temperature+10ºC | |||
| Driven way | Direct Driven | |||
| Noise level at 1 meter | 70+3dB(A) | |||
| Cooled method | Air cooling | |||
| Oil content | 1~3 ppm | |||
| Outlet Connection | Rc 1 | |||
| Dimension | Length(mm) | 1200 | ||
| Width(mm) | 800 | |||
| Height(mm) | 1100 | |||
| Weight(kg) | 520 |
