New Design Microfiltration Machine for Raw Water Treatment

Overview:A microfiltration machine is a mesh filter that traps small suspended solids. It has a drum-shaped metal frame. The drum rotates around a horizontal axis and is supported by stainless steel (or copper wire or synthetic) filaments network. It

Technical Feature

  • Qingdao, China
  • 20sets/Month
  • L/C, T/T, D/P, Western Union, Paypal, Money Gram
  • Combined Treatment
  • Industrial
  • Seaworthy Package
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$0~12

PRIMARY PARAMETERS

Model NO.
RBWL
HS Code
8421299090

DETAIL DESCRIPTION

Overview:
A microfiltration machine is a mesh filter that traps small suspended solids. It has a drum-shaped metal frame. The drum rotates around a horizontal axis and is supported by stainless steel (or copper wire or synthetic) filaments network. It can be used to filter raw water from waterworks and remove algae, leeches and other plankton. It can also be used for filtration treatment of industrial water, recovery of swimming materials in industrial wastewater, and final treatment of sewage.
The microfiltration machine is a 80-200 mesh/in2 microporous screen fixed to a rotary drum type filter device, and intercepts the solid particles in the aquaculture water to achieve a solid-liquid separation purification device. At the same time as filtering, the microporous screen can be cleaned in time by rotating the drum and recoil the force of the water. Keep the device in good working condition at all times. Our company's microfiltration machine is one of the best technology for the treatment of seawater recirculating water aquaculture, aiming at the problems that the existing microfiltration machine is easy to be blocked, easily damaged, easily corroded and difficult to maintain. The product is used to purify the water body through the separation of the solid waste in the aquaculture water to achieve the purpose of recycling.

Working principle:
The working principle of the microfiltration machine is that when the aquaculture water passes through the microporous screen on the microfiltration drum, the solid waste in the aquaculture water body is separated under the rotating action of the rotating drum, so that the water body is purified and recycled. At the same time as filtering, the rotation of the drum and the force of the backwash water can be used to make the microporous screen clean in time, so that the device can always maintain a good working condition.

Advantages:
1, the equipment head loss is small, energy-saving and efficient.
2, compact structure, small occupied space.
3, automatic backwash device, stable operation, easy management.
4, seawater factory farming special microfiltration machine.
5. Application of 316L stainless steel and advanced corrosion-resistant materials to enhance seawater corrosion resistance.


Model
RBWL1

RBWL2

RBWL3

RBWL4

RBWL5

RBWL6

Capacity(m3/h)

50-100

80-150

100-200

120-240

150-300

250-500

Filter surface(m2)

5

7

9

11

14

20

Mesh

60-250

Power(kw)

1.1

1.1

1.5

2.2

3

4




Clients from different countries:
New Design Microfiltration Machine for Raw Water Treatment
New Design Microfiltration Machine for Raw Water Treatment

We always put the quality as the first consideration!
     For further information ,feel free to contact Rachel!


New Design Microfiltration Machine for Raw Water Treatment



FAQ

1.Q:Are you a factory or trading company?
  A: We are a factory, we have rich experience for manufacturing water processing equipment for more than 10 years.


2.Q:Where is your factory located? How can I visit there?
  A:  Our factory is located in No.1137, Zhucheng city, Shandong Province, China. It is about 2 hours from Qingdao airport. We can pick you up if you need, welcome to visit our factory.


3.Q: Do you have  minimum order quantity request?
  A: No minimum order, but it can get a discount if you order a large quantity.


4.Q: Do you have  certificates?
  A: Yes, we have ISO,SGS certificate.


5.Q: Can you meet my special requirements for my products?
  A: Yes, we have a professional design team. We can provide drawings according to your requirements.

6. Q:How do I buy your idea products?
   A:You can provide us your water sources, water quality, flow rate and ground area (contact us for more details).

7. Q:How do I pay?
  A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.

8. Q:What is the delivery time?
  A: It depends on order quantities. Generally speaking, the delivery time will be within 4 to 6 weeks.

9. Q: How do you pack the products?
  A: We use standard package. If you have special package requirements, we will pack as required, but the fees will be paid by customers.

10. Q: How do you keep your equipments from corrosion?
    A: We use the world-famous paint, like SigmaCoatings, PainBow,etc. What's more, we paint strictly according to the standard process.

11. Q: How do you manufacture your equipment ?
    A:Our  machining technology  includes laser/plasma cutting, automatic welding,CNC cutting and bending.


12. Q:How do we install after the equipments arriving destination?
    A: We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you. However, the visa fee, air tickets, accommodation, wages will be paid by buyers.
