Vacuum Evaporator/ Jam Concentrator (ACE-ZFQ-Q8)

 Vacuum Evaporator/ Jam Concentrator (ACE-ZFQ-Q8) ApplicationThe  set can be used to condense and distill liquid material and reclaim organic solution in pharmacy,food and chemical.ComponentThe QN series Ball type vacuum concentra

Technical Feature

  • Ningbo, China
  • 20sets Per Month
  • L/C, T/T, Western Union, Paypal
  • New
  • Customized
  • 110V-480V Customized
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$0~0

PRIMARY PARAMETERS

Model NO.
ACE-ZFQ-Q8
Main Material
SUS304/SUS316L
Warranty
1 Year
Inner Wall Treating
Mirror Polish
Heating Source
Steam Heating /Hot Oil Electric He
Agitator Type
Scraper Type
Work Pressure
-0.090MPa
Function
Remove Moisture From The Feeding
Trademark
ACE
Transport Package
Soft Clothed or Wooden Box
Specification
CE, GMP
Origin
Wenzhou, Zhejiang, China
HS Code
8474390000

DETAIL DESCRIPTION

 Vacuum Evaporator/ Jam Concentrator (ACE-ZFQ-Q8)


Application

The  set can be used to condense and distill liquid material and reclaim organic solution in

pharmacy,food and chemical.

Component

The QN series Ball type vacuum concentrator mainly consists of four parts, i.e. main body of concentrator, condenser, vapor and liquid separator, liquid barrels. It may be used for concentration and distilling of liquid or recycling of organic solvent of pharmacy, foodstuff and chemical industries.
Vacuum Evaporator/ Jam Concentrator (ACE-ZFQ-Q8)


Advantage

By adopting reduced pressure concentration, it has short concentration time and does not destroy effective content of heat-sensitive material.

The parts in contact with material in this equipment made of Ocr18Ni9 stainless steel with good corrosion resistance and long durability and in conformity with sanitary requirement for medicine.


Vacuum Evaporator/ Jam Concentrator (ACE-ZFQ-Q8)
Vacuum Evaporator/ Jam Concentrator (ACE-ZFQ-Q8)

Vacuum Evaporator/ Jam Concentrator (ACE-ZFQ-Q8)

Technology parameter

Model and specification



QN-300

QN-500

QN-700

QN-1000

Transpiration rate

(kg/h)

70

120

145

195

Volume

(L)

300L

500L

700L

1000L

Steam pressure

(Mpa)

0.09

Vacuum degree

(mmHg)

500~620mmHg

Heating area

(m2)

1.3

1.5

2

2.8

Condensing area

(m2)

2.4

3

3.5

4

Equipment  weight

(kg)

380

450

630

950

Outsize dimension

(mm)

L

1900

2030

2100

2335

W

1100

1200

1300

1520

H

2300

2500

2600

2765






Vacuum Evaporator/ Jam Concentrator (ACE-ZFQ-Q8)




Vacuum Evaporator/ Jam Concentrator (ACE-ZFQ-Q8)
