GD folding belt filter

Features

GD folding belt filter is super separation equipment of solid and liquid that our developed basis on foreign advantage technology. It is a filter that can continuously filter, dewater, dry and discharge under the function of vacuum. The unique design and perfect function make this machine can use in thickening and filtering of the material with lower solid phase concentration and high viscosity and fine particles.

Custom service according to different requirement

Advanced construction, super quality extraordinary capacity, lower filter cake humidity, easy to discharge filtrate clarified degree is high, less solid content, high recovery rate

Simple processing, save material, money and effort simple operation, easy to use

Working principle

GD type filter is filter cloth travel type separation equipment of solid and liquid. During running, under the vacuum suction, the liquid of material in vat enter into distributing valve through pipettes after filter media, then from outlet pipe of distributing valve to discharge cylinder or gas-liquid separator and get out, the solids form filter cake on the filter cloth. The filter cake discharged by roll with running of filter cloth. Filter cloth enters into the cloth-wash box and regeneration after HP water flushing and back to drum surface from tension roll to begin new filtration cycle.
