Specifications
inner heated fluid bed dryer is developed based on normal fluid bed
Energy saving, low running cost
The amount of drying air is less; the power consumption is low.
The drying capacity is high; the volume of equipment is small; the area occupied is less.
The operation flexibility is high; the operation of system is steady.
Adopt special air distributing board, so to avoid leakage of material, and it's good for discharging material of big particles.
Working principle and advantages:
Raw material are spreaded on the conveying belt through suitable auxiliary mechanism such as distributor, vibrating belt, pulverizer of granulator, belt passes the channel which containing one or several heating units; heating unit is equipped with air heater and circle system. Each channel has one or several damp exhaust system. When raw material is transited, hot air passes through or over it, in this way it makes raw material dry uniformly.
Application:
The mesh belt dryer is a common continuous drying equipment, it is widely applied in chemical , foodstuff, pharmacy, construction material, and electronic industry, and particularly it is adapt to dry the raw material which have good air permeability and shaped in sheet, strip or granule. For ointment stuff, the wisest way to dry it are : shaped those stuff first, then drying it
Features:
Amount of air, heating temperature, time of material sticking on the belt and velocity of feeding material can be adjusted in order to obtain the best drying effect.
Equipments configuration is very flexible. It can use the netlike belt washing system and cooling raw material system
Hot air can be circularly applied, the energy is greatly saved
Unique air dividing device, it makes hot air distribute uniformly; this can guarantee products quality
Heating source can be selected from steam, conducting heat oil, electricity, coal furnace and oil burner
Lysine powder fluid bed drier ,vibrating fluidized bed dryer, salt fluid bed dryer, continuous fluid bed dryer
Model | DWT-1.6-I Fed table | DWT-1.6-II Middle table | DWT-1.6-III Discharge table | DWT-2-I Fed table | DWT-2-II Middle table | DWT-2-III Discharge table |
Belt width (m) | 1.6 | 1.6 | 1.6 | 2 | 2 | 2 |
Drying section length (m) | 10 | 10 | 8 | 10 | 10 | 8 |
Thickness of the material to be covered (mm) | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 |
Temperature (°C) | 50-150 | 50-150 | 50-150 | 50-150 | 50-150 | 50-150 |
Area of heat conduction(m2) | 525 | 398 | 262.5 | 656 | 497 | 327.5 |
Steam pressure (Mpa) | 0.2-0.8 | 02-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 |
Drying time (h) | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 |
Power (kw) | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
Overall Dim. (m) | 12x1.81x1.9 | 12x1.81x1.9 | 10x1.81x1.9 | 12x2.4x1.92 | 12x2.4x1.92 | 10x2.4x1.92 |
