Fingerprint RFID Semi-Automatic Access Control System Vertical Tripod Turnstile Gate Professional Turnstile Manufacturer

This series of turnstile adopt the unique technology of our company---the precise photo electricity limit and gear to orient the closure.

Technical Feature

  • Guangdong, China (Mainland)
  • WEJOIN
  • WJTS111S
  • Die-casting Alloy Aluminum
  • Iron with Powder
  • RS232
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Place of Origin
Guangdong, China (Mainland)
Brand Name
WEJOIN
Model Number
WJTS111S
Mechanism Material
Die-casting Alloy Aluminum
Cabinet Material
Iron with Powder
Communication
RS232
Dimension
420*380*1050 mm
Power supply
DC12V
Transit Speed
30~45 persons / min
Rotating Direection
Double Direction
Length Of Pole
490mm
Working Environment
Indoor / Outdoor ( Shelter)
Driving Motor
Brushless DC Motor

DETAIL DESCRIPTION

Product Description

Product Application

This series of turnstile adopt the unique technology of our company---the precise photo electricity limit and gear to orient the closure. The turnstile be unlocked and reset because of the specific motor. The closure is very precise and stable. This series of turnstile adopt standard electricity socket. It can read boom code card, ID card, 1C card and so on.

There is a series of turnstiles. You can choose Che item and specidcalion. They can be used in hold, school, meira and chamber and so on. This series is of very high-tech. In order lo guarantee it can run safely, please carefully read this instruclion!

Model
WJTS122S
WJTS112S
WJTS110S
WJTS111S
Item
Driving Model
Electro  Magnetic
Material of housing
304 Stainless Steel
Iron with Powder
Dimension of housing (L*W*H mm)
420*380*1000
1235*280*1000
1230*280*1000
420*380*1050
Thickness of housing
1.5mm
Length of pole
490mm
Net weight
40kg
70 kg
70 kg
35 kg
Max load-bearing of pole
80kg
Driving force of pole
3kg
Rotating direction
Double direction
Power supply
220V±10%, 110± 10%
Frequency
50/60HZ
Working voltage of motor
DC12V
Rated power
36W
Driving motor
Brush-less DC motor
Input interface
Dry contact with the pulse between 200ms~500ms
Transit speed
30~45 persons/min
Working temperature
-25°C~55°C
Working environment
Indoor / Outdoor (Shelter)
Relative humidity
≤95%, no condensation
Relative humidity
≤95%, no condensation

Main Features

Semi-automatic
1) Exquisite rotating plate and a self-lock mechanism
2) Passable for bi-direction
3) Self-locking within 5 seconds
4) Arm auto dropping when power off
5) Avoid unauthorized access
6) Counter output
7) Fire alarm emergency signal output
8) Input interfaces available for left access(L),right access(R),emergency(EM),GND

Detailed Images



Feature: Special Designed Mechanism


Exquisite rotating plate and a self-lock mechanism



Feature: Bi-direction passes


When reading card from a certain side, the indication light direct the opposite direction.



Feature: Droping Arm When Power Off


Arms drop automatically when power off.




Feature: Arm Rise Up Automatically


Arms rise up automatically when power on.


Feature: Green&Red light indicator


Traffic light indicator Show Green light show this way can passed by reading card, show red show this way can not passed.


Counter


Passenger counters ( There have interface on PCB for card reader and counter)



Feature: Mutil-working Model

Both directions can be set as controlled mode or free mode.

Certifications
Quality Control

All Product Tests Before Delivery:

WEJOIN utilizes advanced testing equipment and various testing methods in all production processes.

Our Company
Packing & Delivery
Packaging
Size
112*50*53CM
Weight
50 kg



Packaging Details
The normal package is wooden box(Size: 112*50*53CM). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Our Service
Pyment Term
Leading Time
Minimum Order
Supply Ability
Package
T/T; West Union
5-7 working days
1 Unit
10,000 Unit/ Month
Paper Carton or Wooden Box

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

Application Scenario
