Functions and features:
1. Unique incomplete wheel transmission is adopted to make turnstiles held or unheld in zero position more accurate and reliable;

2. Running stable, little noise and no mechanical impact;

3. Self-checking-power-on function, if power on, turnstile will auto get to be held

4. Various working means can be set in the control panel menu, namely bi-direction card reading passing, or one direction card

    reading passing and another passing limits, or one direction card reading passing and another free passing and more;

5. If power off, arm will fall automatically while power on later, arm should be lift by hand, first press the arm with a little force and then lift it manually;

6. It is with RS485 connection for far control arm up and down to satisfy the special needs or fire control requirements;

7. It is with standard electrical interface to connect various kinds of readers and writers for easy integration and also computer

    far control and management can be realized by computer;

8. It will count the persons who have been passed through automatically and will show the number by LED directly

    (LED is optional);

9. Passing direction will be shown by LED and passengers will know which direction is allowed to pass;

10. Card reading memory or card reading without memory function can be set in the control panel menu according to your

      request;

11. If working with software, the total-in-population can be set to satisfy special request;

12. Re-position function. after card reading, if passenger not through within the specific time, time and the limit passing time

      length can be set;

13. Card mounting is available;

14. Uncompleted wheel turning system is adopted for locking the turnstile in zero, and unlocking will be more reliable and accurate;

15. Optional:
1) Half height turnstile counter and counter display;
2) Access controller or card reader;
3) Key by-pass;

Packing details:

440*350*1010mm/wooden box

G.W/kgs/carton:65kg
