ge steam turbine

In the face of oversea customers, our service department has a quick response to supply the better and faster international service for the customers all over the world.

Technical Feature

  • Zhejiang, China (Mainland)
  • CHTC
  • CHTC N
  • Generator
  • Biomass Gasification
  • 2200000
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Place of Origin
Zhejiang, China (Mainland)
Brand Name
CHTC
Model Number
CHTC N
Type
Generator
Electricity Generator Type
Biomass Gasification
Output Voltage (V)
2200000

DETAIL DESCRIPTION

In the face of oversea customers, our service department has a quick response to supply the better and faster international service for the customers all over the world.



High temperature high pressure condensing steam turbine, extraction condensing steam turbine, high temperature & pressure prefix steam turbine is specially designed and manufactured for iron & steel industry and thermoelectric reformation. To improve energy utilization and energy conservation & emissions reduction has made a new contribution.



C series are single casing & single shaft or double casing & double shaft extraction condensing steam turbine. The inlet parameters are from 1.27MPa/350°C to 13.23MPa/550°C, outputs are 3MW, 6MW, 12MW, 15MW, 20MW, 25MW, 50MW, 75MW with 8 modes and 32 series totally. The speed of turbine is 3000rpm and turbine connects with generator directly



N series steam turbines are single casing & single shaft or double casing & double shaft condensing steam turbine. The inlet parameters are from 2.35MPa/390°C to 13.23MPa/550°C, outputs are 6MW, 9MW, 12MW, 15MW, 20MW, 25MW, 30MW, 35MW, 50MW, 75MW with 10 modes and 30 series totally. The rotation speed of turbine is 3000 rpm and turbine connects with generator directly.



BN series steam turbines are single casing & single shaft or double casing & double shaft induction condensing steam turbine. The inlet parameters are from 1.27MPa/350°C to 13.23MPa/550°C, induction pressure are from 0.15MPa to 4.5MPa, induction temperature are from saturated to superheat, outputs are 3MW, 4.5MW, 6MW, 7.5MW, 9MW, 12MW, 15MW, 18MW, 20MW, 25MW, 30MW, 40MW, 50MW, 65MW with 14 modes and 40 series totally. The speed of turbine is 3000 rpm and turbine connects with generator directly.



B series steam turbines are single casing & single shaft and multistage back pressure steam turbine. The inlet parameters are from 1.27MPa!350°Cto 13.23MPa/550°C, exhaust pressures are from 0.2Mpa to 5.88Mpa, outputs are 3MW, 6MW, 9MW, 12MW, 15MW, 20MW, 25MW, 40MW, 50MW with 9 modes and 27 series totally. The rotation speed of turbine depending on the design requirements, from 3000rpm to 10000rpm differently. Most of them directly connect to the generators and some others connect to generators by reduction gear box.



 CB series steam turbines are single casing & single shaft extraction back pressure steam turbine. The inlet parameters are from 1.27MPa/350°Cto 13.23MPa/550°C, extraction pressures are from 0.7MPa to 5.0MPa, exhaust pressures are from 0.2MPa to 4.0MPa. Outputs are 6MW, 9MW, 12MW, 15MW, 20MW, 25MW, 40MW, 50MW, 75MW with 9 modes and 27 series totally. The rotation speed of turbine is 3000 rpm and turbine connects with generator directly.
