Sodium Citrate Vacutainer Tube Automatic Production Line
China's FIRST manufacturer of blood collection tube automatic production machines
Since 2003, HONGREAT designed the FIRST set blood collection tube automatic production machine successfully. Through 15 years practical application production, and constant feedback from customers, HONGREAT is making continuous efforts on innovation, maintaining its leadership in technology and market, becoming the preferred partner and equipment supplier of lots of public companies and large-scale production enterprises.
Sodium Citrate Vacutainer Tube Automatic Production Line
• Application: Full automatic production line of blood collection tubes(vacuum & non-vacuum).
• Process flow: Tube loading→Reverse tube detection→EDTA / Heparin / BCA /Sodium citrate dosing -spraying →Drying (except citrate)→Cap adding→Vacuuming→Transferring tube to foam tray
| Production capacity | 8,000-12,000 pcs/h |
| Tube kinds | EDTA K2/K3, Heparin, BCA (Clot activator), BCA+Gel, Sodium citrate |
| Tube size | Ø13*75mm; Ø13*100mm (available for PET, PP, Glass) |
| Cap size | Outer Ø16±0.05*19mm+0.1 |
| Control way | Touch screen operation, PLC Control |
| Dosing system | 5 set of precision ceramic metering pump for EDTA K2/K3: 20-50ul±6%; 5 set of precision ceramic metering pump for Sodium citrate:100-900ul±4%; 10 set of metering valve for BCA: 20-50ul±10% |
| Drying system | 3 sets of “PTC” dust-free drying system |
| Detecting system | Reverse tube detection before additive dosing-spraying Alarm function in case of lack of foam tray storage. |
| Vacuum degree | 0 ~ -95Kpa ±5% for vacuum tubes; 0 for non-vacuum tubes (Numerical control for vacuum pressure, Frequency conversion control for vacuum pump) |
| Configurations | 1) Tube loading system 2) Reverse tube detection 3) EDTA dosing system (5 set) 4) BCA dosing system (10 set) 5) Sodium citrate dosing system (5 set) 6) PTC dust-free drying system (3 set) 7) Cap adding system 8) Vacuum & cap-pressing system 9) Transferring to foam tray system |
| Air consumption | Max. 1m3/min; Air supply pressure P: 0.7Mpa≤P≤1Mpa |
| Power | 30KW/AC380V |
After more than 10 years of usage test by over 100 customers, HONGREAT has been focused on technological improvement, based on customer tracking service and feedback data, accumulated extensive experiences in production and technical solutions.
Stable, Reliable, Unbelievable low failure rate and humanized design, HONGREAT has won the trust from lots of customers.
HONGREAT has a core technical team, with more than 10 years of experience in R&D, production and service. Concentrating on each production link, by using innovation to create more value for manufacturing enterprises. HONGREAT refreshed techniques and efficiency of blood collection tube automatic production again.
Unique Inverted Tube Detection and Alarm System
Control every production link
HONGREAT unique inverted tube detection system, alarms timely in case of any tube direction inversion by worker’s misoperation while placing tubes, and will not pass into additive dose-spraying process, avoiding damaging the expensive precision spray system or affecting production.
Precision Ceramic Dosing-spraying System
HONGREAT newly self-developed customized ceramic metering dosing-spraying system, has low failure rate and accurate dosage. Plunger and plunger kit are made of high purity precision ceramic, normal working life reaches 100,000,000 times.
* Applied with leading SMC 3-axis or dual-axis servo control, nozzles rise gradually while spraying, which can spray more evenly. Product quality and test effect can be greatly improved.
HONGERAT developed various kinds of accurate and stable dosing system
optional for different BCT production demand.
1. EDTA K2 /K3: 5 or 10 nozzle precision ceramic spraying system optional;
2. Sodium citrate: 5 or 10 nozzle precision ceramic dosing system optional;
3. Lithium / Sodium Heparin: 5 or 10 nozzle precision ceramic spraying system optional;
4. BCA:10 nozzle precision spraying system optional;
PTC hot-air drying, finish good quality can be improved
Adopted with dust-free “PTC” heating mode, heat faster, temperature control more accurately.
Production efficiency and quality can be improved.
Precise Vacuum Digital Automatic Control System
HONGREAT self-developed intelligent digitized vacuum compensation system, vacuum degree is auto-compensated during vacuuming and cap-pressing. Intuitive control interface, simple and easily use even for ordinary workers. Vacuum blood tube of stable and high quality can be guaranteed in production process.
Frequency Converting Vacuum System
Latest frequency technology for vacuum pump, working / standby mode is selected automatically while machine running. Workload of pump is reduced, energy-saving, which is more, vacuum pump working life is extended.
Equipped with internet interface Simpler maintenance
HONGREAT blood collection tube automatic intelligent production machines are equipped with Internet remote maintenance interface. Wherever the customer is, we can solve faults for customers quickly and timely.
HONGREAT is a company who is focusing on the intelligentization and innovation of BCT production.We have a core technical team, with more than 10 years of experience in R&D, production and service. Concentrating on each production link, by using innovation to create more value for manufacturing enterprises.
Through 15 years of practical application experience and constant feedback from 100 enterprises, we refreshed techniques and efficiency of BCT automatic production, each patents is our solid footprint.
