Best Pregelatinized Starch Production Line/Processing line

its barrel and screws are properly adjusted for the purpose of widening the extrusion and inflating functions.

Technical Feature

Shandong, China (Mainland)

SBN

SLG

Modified Starch Machine

Engineers available to service machinery overseas

Best Pregelatinized Starch Production Line/Processing line

Send Project Inquiry

Add Inquiry List

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Place of Origin

Shandong, China (Mainland)

Brand Name

SBN

Model Number

SLG

Type

Modified Starch Machine

After-sales Service Provided

Engineers available to service machinery overseas

Project

Best Pregelatinized Starch Production Line/Processing line

Capacity

150-500KG/H

Raw material

Flour starch

Automatic line

Low electric cost

Craft

Exrusion

Certification

Contact

Carol

Mobile

0086 18553102336

DETAIL DESCRIPTION

Best Pregelatinized Starch Production Line/Processing line

1. Production DescrIption

This modified starch machine/pregelatinization starch machine, also called modified starch machine, is specially designed.its barrel and screws are properly adjusted for the purpose of widening the extrusion and inflating functions. The modified starch products made by this machine can be used in many fields like spinning, food, paper making, building materials, casting, oil drilling and other chemical plant ect industies. This machine will definitely play a more important role in pregelatinization starch field.

This starch processing equipment is composed of feeding system, extrusion system, cutting system, heating system, conveying system and cooling system.Our pregelatinization starch machine have many different capacity for your choice.

Please contact us if you need it.

2. Flow chart

This line contains the following machine:

Mixer—— Screw conveyor—— Twin-screw extruder—— Air conveyer—— Seven-layer oven ——Cooling conveyor —— Air conveyor—— Miller

3.Technical parameters:

Model
Parameter
SLG 65-III Modified Starch processing line
SLG70-II Modified Starch processing line
SLG85-II Modified Starch processing line
Installed capacity
74KVA
106KVA
204KVA
Power
40-50kw
55-65kw
65-75kw
Output
140-160kg/h
240-260kg/h
500-600kg/h
Dimension
14×2×4m
14×2×4m
21×2×4m

4.Sample Photoes

Our Service:

1.Provide you with the professional advice on the market,equipments,raw materials and production line ect.
2.Assist you to choose the ideal equipment,design the flow and we can offer on-site service.
3.Make rational plan to the changeover of the material according to your final product, even we can perform the process at site.
4.Specially design the machines,practice test and provide relevant training as you required
5.Provide reasonable packing and transportation plan, send technician to install and debug the machines

Thanks for your attention!
Please call Carol Liu 0086 18553102336
