1.Specification:
| Model | SLG65 | SLG70 | SLG 85 |
| Install Power | 65KW | 110KW | 190KW |
| Consumption Power | 42KW | 77KW | 133KW |
| Output | 120-250 KG/H | 220-260 KG/H | 500-600 KG/H |
| Dimension | 19000x1300x2200M | 22000x1300x2200M | 30000x1300x2500M |
2.The brief description of China new product modified starch processing line:
China new product modified starch processing line uses cheap natural starch, like corn starch, cassava starch, tapioca starch etc as main materials, through extruding treatment process, to produce multi-functional and high-valuable modified starch, Pre-gelatinization Starch or Denatured Starch. Its Double Screw Extruder is special designed, consists of 6 systems: feeding system, extruding system, cutting system, heating system, conveying system and cooling system, its barrels and screws structure can easily realize the function of changing the properties of the starch. Modified Starch can be used in many fields like Textile, Food, paper making, building material, casting, oil drilling and so on.
3. Raw Materials: natural starch, like corn starch, cassava starch, tapioca starch etc
4. Products: Modified Starch.
5. Capacity: 120150 KG/H,200-250 KG/H,400-500 KG/H
6. Flow Chart: Mixing —Extrusion —Baking —Grinding
7. Voltage: Three phases: 380V/50HZ, Single phase: 220V/50HZ, we can make it according to customers' local voltage of different countries.
8. Machines Materials: All the machines are made by food grade stainless steel.
Jinan Saibainuo Machinery Co., Ltd for food machine manufacturering in China since 2004, offer competitive advantage machines, so with us your money in safe, your business in safe.
Our modified starch production line in our factory.
The inside structure of our twin screw extruder.
Our gas dryer, we also have electricity/diesel/steam dryer for your selection.
Name: high speed mixer
Dimension(m): 1.1×0.8×1.4
Motor Power: 4KW
Speed: 400rpm
Throughput: 30kg per loading (5-6 minutes per loading)
Functions:
Mix powder raw material with water
Features:
1. stainless steel material
2. new handle-opened design of discharge holes,no material leak
3.High speed can mix material better than other slow mixer.
Name: screw conveyor
Dimension(m): 3.2×0.6×0.7
Motor Power: 1.1KW
Screw speed: 300rpm
convey height range:1.5~2.5M
barrel diameter: Φ141mm
Function:
Power material can be conveyed in the stainless steel roller to the feed machine of extruder without leaking, dust and pollution; feed quantity is even and stable.
Features:
stainless steel material.
Name: high speed mixer
Dimension(m): 2.6×1.0×1.3
Total power: 37kw
Main Motor Power:22KW
Feeder motor:0.75kw
Cutting motor: 1.5kw
Heating power:12kw
Extruder diameter:Φ65 mm
Function:
Extrude and cook raw material into different size and shapes
Features:
Screw material is 38CrMoAl with nitriding treatment, the
hardness is 60HRC..
The barrel also use good material, hardness is 55HRC.
The gear box has forced lubrication system.
All motors can be adjusted the speed by Inverter.
The Extruder can change different molds to produce different Shapes product.
Name: multi-layer dryer
Dimension(m): 5.4×1.3×1.8
Heating Power:27kw
Motor power:0.75kw
Belt speed:0.1-10M/minute
Temperature: 20-200℃
Function:
There are three layers inside,each layer is 5 meters long, it can save space and energy. Electricity heating,used to bake and dry food.
Features:
The net belt running speed can be controlled by Inverter, to change the food drying time in the dryer.
Heating adopts the electric heat tube.
It has automatic temperature Control system.
The belt and the cover are all stainless steel.
Name: milling machine
Dimension(m): 1.1×0.6×0.5
Motor Power: 11KW
Functions:
Mill the puffed product into powder
Features:
Low energy-consumption, high efficiency.
Stainless Steel.
Before sale services:
1.Provide the free consultation of the equipment.
2.Provide the standard device and the flow chart.
3. According to the clients’ special requirement, offering the reasonable plan and free design helping to select the equipment.
Services during the sales:
1.Help client design the factory and offering professional advice, free engineering drawing for the factory layout.
2.Welcome to visit our factory or the domestic clients’ factory.
3.Inspect the machine before leaving the factory.
After sale services:
1.Oversea install and debug the equipment.
2.Train the first-line operator.
3.Provide the basic formula.
Packaging & Shipping:
1).packaging: daub coal oil on the surface to protect the machine from moisture, Then cover with plastic film.Finaly pack them with wooden case.
2).If you want to know the transportation cost: by air-please tell me your airport name; by express-please tell me your detailed address(including zip code,house number,street,city,country); by ship-pls tell me your delivery port.
