0.6/1kv N2xry Low Voltage XLPE Insulated Armoured Cables

PRIMARY PARAMETERS

Model NO.

N2XRY

Wire Core Material

Copper

Certification

CCC, CE

Model

N2xry

Brand

Rated Voltage

0.6/1 Kv

Number of Core

1-5

Refer Standard

IEC 60502-1

Type of Armor

Steel Wire(Swa) Steel Tape(Sta)

Trademark

Transport Package

Wooden Drum/Steel Drum

Specification

1.5-630 Mm2

Origin

Jiangsu, China

HS Code

8544492100

DETAIL DESCRIPTION

0.6/1kv N2XRY Low Voltage XLPE Insulated Armoured Cables Application:
IEC 60502-1 cables are used for electricity supply in low voltage installation system, IEC 60502-1 cables are
suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations,
local energy distributions, industrial plants, where there is no risk of mechanical damage.
0.6/1kv N2XRY Low Voltage XLPE Insulated Armoured Cables Construction:
Conductors: Copper or Aluminium conductor, round standed or Shaped confirm to Class1 or class2
Insulation:XLPE

Assembly : Two, Three or Four insulated conductors are laid-up together with non-hygroscopic fillers
Inner Sheath and the assembly:PVC
Armour: Aluminum/Galvanized Steel Wires
Outer Sheath: PVC Outer sheath

Single core parameter

Nominal Cross Section	Diameter of Conductor (Approx.)	Nominal Insulation thickness	Nominal Inner Covering thickness	Nominal Alum Wire dia.	Nominal Sheath thickness	Overall Diameter (Approx.)
mm²	mm	mm	mm	mm	mm	mm
1x4	2.3	0.7	1	0.8	1.8	10.9
1x6	2.8	0.7	1	0.8	1.8	11.4
1x10	3.6	0.7	1	0.8	1.8	12.2
1x16	4.5	0.7	1	0.8	1.8	13.1
1x25	5.6	0.9	1	0.8	1.8	14.6
1x35	6.7	0.9	1	1.25	1.8	16.6
1x50	8	1	1	1.25	1.8	18.1
1x70	9.4	1.1	1	1.25	1.8	19.7
1x95	11	1.1	1	1.6	1.8	22
1x120	12.4	1.2	1	1.6	1.8	23.6
1x150	13.8	1.4	1	1.6	1.8	25.4
1x185	15.3	1.6	1	1.6	1.8	27.4
1x240	17.5	1.7	1	1.6	1.9	29.9
1x300	19.5	1.8	1	2	2	33.1
1x400	22.6	2	1.2	2	2.2	37.3
1x500	25.2	2.2	1.2	2	2.3	40.5

Two core cable Parameter:

Nominal Cross Section	Diameter of Conductor (Approx.)	Nominal Insulation thickness	Nominal Inner Covering thickness	Nominal Steel Wire dia.	Nominal Sheath thickness	Overall Diameter (Approx.)
mm²	mm	mm	mm	mm	mm	mm
2x1.5	1.4	0.7	1	0.8	1.8	12.8
2x2.5	1.8	0.7	1	0.8	1.8	13.6
2x4	2.3	0.7	1	0.8	1.8	14.6
2x6	2.8	0.7	1	1.25	1.8	16.5
2x10	3.6	0.7	1	1.25	1.8	18.1
2x16	4.5	0.7	1	1.25	1.8	19.9
2x25	5.6	0.9	1	1.6	1.8	23.6
2x35	6.7	0.9	1	1.6	1.8	25.8
2x50	8	1	1	1.6	1.9	29
2x70	9.4	1.1	1	2	2 .3	3.2
2x95	11	1.1	1.2	2.1	3	7.1
2x120	12.4	1.2	1.2	2	2.3	40.5
2x150	13.8	1.4	1.2	2.5	2.4	45.4
2x185	15.3	1.6	1.4	2.5	20.6	49.9
2x240	17.5	1.7	1.4	2.5	20.7	55.1
2x300	19.5	1.8	1.6	2.5	20.9	60.2
2x400	22.6	2	1.6	2.5	30.1	67.7

Three core cable parameter

Nominal Cross Section	Diameter of Conductor (Approx.)	Nominal Insulation thickness	Nominal Inner Covering thickness	Nominal Steel Wire dia.	Nominal Sheath thickness	Overall Diameter (Approx.)
mm²	mm	mm	mm	mm	mm	mm
3x1.5	1.4	0.7	1	0.8	1.8	13.2
3x2.5	1.8	0.7	1	0.8	1.8	14.1
3x4	2.3	0.7	1	0.8	1.8	15.2
3x6	2.8	0.7	1	1.25	1.8	17.1
3x10	3.6	0.7	1	1.25	1.8	18.9
3x16	4.5	0.7	1	1.25	1.8	20.8
3x25	5.6	0.9	1	1.6	1.8	24.7
3x35	6.7	0.9	1	1.6	1.8	27.2
3x50	8	1	1	1.6	1.9	30.6
3x70	9.4	1.1	1	2	2.1	35.2
3x95	11	1.1	1.2	2	2.2	39.3
3x120	12.4	1.2	1.2	2	2.3	43
3x150	13.8	1.4	1.4	2.5	2.5	48.6
3x185	15.3	1.6	1.4	2.5	2.7	53
3x240	17.5	1.7	1.4	2.5	2.8	58.5
3x300	19.5	1.8	1.6	2.5	3	64
3x400	22.6	2	1.6	3.15	3.3	73.5

3+1 core cable parameter

Nominal Cross Section	Diameter of Conductor (Approx.)	Nominal Insulation thickness	Nominal Inner Covering thickness	Nominal Steel Wire dia.	Nominal Sheath thickness	Overall Diameter (Approx.)
mm²	mm	mm	mm	mm	mm	mm	mm	mm
3x 16/10	4.5	3.6	0.7	0.7	1	1.6	1.8	22.7
3x 25/16	5.6	4.5	0.9	0.7	1	1.6	1.8	26.5
3x 35/16	6.7	4.5	0.9	0.7	1	1.6	1.9	29
3x 50/25	8	5.6	1	0.9	1	1.6	2.1	33
3x 70/35	9.4	6.7	1.1	0.9	1.2	2	2.2	38
3x 95/50	11	8	1.1	1	1.2	2	2.3	42.4
3x120/70	12.4	9.4	1.2	1.1	1.2	2	2.5	48
3x150/70	13.8	9.4	1.4	1.1	1.4	2.5	2.7	52
3x185/95	15.3	11	1.6	1.1	1.4	2.5	2.8	57.2
3x240/120	17.5	12.4	1.7	1.2	1.6	2.5	3.1	64
3x300/150	19.5	13.8	1.8	1.4	1.6	2.5	3.2	69.8

Four Core cable parameter

Nominal Cross Section	Diameter of Conductor (Approx.)	Nominal Insulation thickness	Nominal Inner Covering thickness	Nominal Steel Wire dia.	Nominal Sheath thickness	Overall Diameter (Approx.)
mm²	mm	mm	mm	mm	mm	mm
4x1.5	1.4	0.7	1	0.8	1.8	14
4x2.5	1.8	0.7	1	0.8	1.8	14.9
4x4	2.3	0.7	1	1.25	1.8	17
4x6	2.8	0.7	1	1.25	1.8	18.2
4x10	3.6	0.7	1	1.25	1.8	20.2
4x16	4.5	0.7	1	1.6	1.8	23
4x25	5.6	0.9	1	1.6	1.8	26.7
4x35	6.7	0.9	1	1.6	1.9	29.5
4x50	8	1	1	2	2.1	34.2
4x70	9.4	1.1	1.2	2	2.2	38.8
4x95	11	1.1	1.2	2	2.3	42.9
4x120	12.4	1.2	1.4	2.5	2.5	48.6
4x150	13.8	1.4	1.4	2.5	2.7	53.2
4x185	15.3	1.6	1.4	2.5	2.8	58.1
4x240	17.5	1.7	1.6	2.5	3.1	64.8
4x300	19.5	1.8	1.6	2.5	3.2	70.4
4x400	22.6	2	1.8	3.15	3.6	81.3
