We are pipe and steel sturctuer dealers, have been trusted by clients for years.
We are trusted with big orders in 1000 tons per order.
Our shipping service can be in bulk shipping or contaienr to clients need.
Quality is always our top concern.
Choosing us is your very wise choice.
We are trusted with big orders in 1000 tons per order.
Our shipping service can be in bulk shipping or contaienr to clients need.
Quality is always our top concern.
Choosing us is your very wise choice.
1. OD:1/2"-12" (21.34mm-323.85mm)
2. WT:SCH5S,SCH10S,SCH40S (1.65mm-9.52mm)
3. Length:6m,12m or accoding to customer's requests
4. Standad:strictly follow ASTM A312 standard
5. Material: 304 304L 316 316L
6. Technics: Annealed and Pickled
7. Application:Industrial fluid conveying pipes
8. Packing:Bundle packing+ container
9. Delivery:20-25 days
10. Payment: T/T,L/C at sight
| Nominal diameter) | (Outside diameter) | (Nominal Wall Thickness) | |||
| SCH 5S | SCH 10S | SCH 40S | |||
| (A) | (B) | mm | mm | mm | mm |
| 15 | 1/2'' | 21.34 | 1.65 | 2.11 | 2.77 |
| 20 | 3/4'' | 26.67 | 1.65 | 2.11 | 2.87 |
| 25 | 1'' | 33.4 | 1.65 | 2.77 | 3.38 |
| 32 | 11/4'' | 42.16 | 1.65 | 2.77 | 3.56 |
| 40 | 11/2'' | 48.26 | 1.65 | 2.77 | 3.68 |
| 50 | 2'' | 60.33 | 1.65 | 2.77 | 3.91 |
| 65 | 21/2'' | 73.03 | 2.11 | 3.05 | 5.16 |
| 80 | 3'' | 88.9 | 2.11 | 3.05 | 5.49 |
| 90 | 31/2'' | 101.6 | 2.11 | 3.05 | 5.74 |
| 100 | 4'' | 114.3 | 2.11 | 3.05 | 6.02 |
| 125 | 5'' | 141.3 | 2.77 | 3.4 | 6.55 |
| 150 | 6'' | 168.28 | 2.77 | 3.4 | 7.11 |
| 200 | 8'' | 219.08 | 2.77 | 3.76 | 8.18 |
| 250 | 10'' | 273.05 | 3.4 | 4.19 | 9.27 |
| 300 | 12'' | 323.85 | 3.96 | 4.57 | 9.52 |
China
