1.It adopts a thermal flow system and high-pressure injection molding to get high precision of bottle mouth, bottleneck and screw. The product has no seam and leftover bits and pieces. Save raw material. And the products have the same specification and their appearance is beautiful and smooth.
2.The injection section adopts single-screw stem horizontal injection method. The clamping molding section adopts horizontal three-work positions rotary device. It can one-mould multiple-chamber continuous production, it has high efficiency.
3.High voltage locking mould adopts energy storing device, improve production efficiency and save energy source.
4.It adopts auto stripping and auto flame treating and auto counting. Three sections are combined together to ensure the products not be polluted to meet the healthy demands of food and pharmacy trades.
5.Adjust rings can be fixed in mechanical, hydraulic, air-control, electric and others to ensure the technological demands of different products.
6.It has strong applicability to raw materials, such as PE, PP, PVC and others.
7.The machine adopts advanced famous hydraulic and electric components. It has low-mould protection, pressure protection, flowing adjustment and other functions. It has hand-operated, semi-auto and auto operation.
8.The production efficiency of the machine is high. Its noise is low and its power consumption is small, the operation is safe and convenient. It is an ideal equipment to produce package bottles for pharmacy, food and other trades.
Advantages
Servo energy saving injection molding machine output power changes with the loading changing. There's no extra waste of power. The motor doesn't work while cooling, electricity consumption is 0. As compared with the tradition injection molding machine, the servo machine can save electricity 20%-80% that brings you excellent profit.
-Excellent energy saving
As compared with the traditional fixed pump injection molding machine, it saves energy 20%-80% under the same working condition.
-Excellent injection molding stability
The pressure and flow of servo drive system applies closed-loop control, as compared with the traditional injection molding machine, it greatly increases repeatability precision of injection molding.
-Fast response
Fast response servo drive, the start time faster than that of the traditional injection molding machine by 50%.
-Environmental friendly
he complete machine runs under low noisy, low speed operation and quite.
-Constant oil temperature
The servo motor output hydraulic oil according to proportion to avoid extra heat. Even the hydraulic oil need not to be cooled to realize excellent water saving.
| BST-700A | BST-950A | BST-1300A | BST-1600A | BST-2000A | BST-2400A | BST-3000A | BST-3800A | BST-4800A | ||||||||||||||||||
| screw diameter | 32 | 35 | 30 | 35 | 40 | 35 | 40 | 45 | 45 | 50 | 55 | 50 | 55 | 60 | 55 | 60 | 65 | 60 | 65 | 70 | 65 | 70 | 75 | 70 | 75 | 80 |
| screw l/d ratio(l/d) | 20 | 18.8 | 24.5 | 21 | 18.4 | 24 | 21 | 18.7 | 23.3 | 21 | 19.1 | 23.1 | 21 | 19 | 22.9 | 21 | 19.4 | 22.7 | 21 | 19.5 | 22.6 | 21 | 19.6 | 22.6 | 21 | 19.7 |
| theoretical shot volume(mm³) | 113 | 135 | 113 | 154 | 201 | 173 | 226 | 286 | 358 | 442 | 534 | 491 | 594 | 707 | 665 | 791 | 921 | 848 | 995 | 1154 | 1061 | 1231 | 1413 | 1346 | 1545 | 1758 |
| shot weight(ps)(g) | 101 | 121 | 103 | 140 | 183 | 158 | 206 | 260 | 326 | 402 | 486 | 447 | 540 | 643 | 605 | 720 | 845 | 772 | 905 | 1050 | 966 | 1120 | 1286 | 1225 | 1406 | 1600 |
| injection pressure(mpa) | 232 | 194 | 249 | 183 | 140 | 235 | 142 | 142 | 219 | 178 | 147 | 215 | 178 | 149 | 210 | 176 | 150 | 207 | 176 | 152 | 203 | 175 | 152 | 201 | 175 | 154 |
| theoretical injection rate(ps)(g/s) | 62 | 72 | 67.5 | 91.8 | 120 | 110 | 181 | 182 | 142 | 175 | 212 | 145 | 175 | 208 | 176.5 | 210 | 245 | 241 | 283 | 328 | 308 | 357 | 410 | 370 | 423 | 484 |
| plasticising capacity(g/s) | 11 | 12 | 8.3 | 12.5 | 18 | 13.8 | 19.7 | 27.1 | 20.1 | 26.5 | 34.2 | 22.5 | 28.7 | 35.4 | 26.4 | 32.5 | 40 | 35.2 | 43.3 | 51.8 | 50.6 | 60.5 | 71.5 | 60.4 | 71.4 | 83.7 |
| max.screw rotate speed(t/min) | 220 | 260 | 250 | 200 | 170 | 150 | 150 | 150 | 150 | |||||||||||||||||
| injection stroke(mm) | 140 | 160 | 180 | 225 | 250 | 280 | 300 | 320 | 350 | |||||||||||||||||
| clamping unit | ||||||||||||||||||||||||||
| max.clamping force(kn) | 700 | 950 | 1300 | 1600 | 2000 | 2400 | 3000 | 3800 | 4800 | |||||||||||||||||
| max.opening stroke(mm) | 290 | 340 | 400 | 460 | 500 | 530 | 590 | 680 | 770 | |||||||||||||||||
| space betweeen(mm) | 320*320 | 360*360 | 420*420 | 480*480 | 505*505 | 555*555 | 610*610 | 680*680 | 760*760 | |||||||||||||||||
| mould height | 120-300 | 135-380 | 160-440 | 180-500 | 190-530 | 200-570 | 220-630 | 250-710 | 280-790 | |||||||||||||||||
| max.daylight(mm)590 | 590 | 720 | 840 | 960 | 1030 | 1100 | 1220 | 1390 | 1560 | |||||||||||||||||
| other | ||||||||||||||||||||||||||
| pump motor power(kw) | 9 | 11 | 13 | 15 | 18.5 | 22 | 30 | 37 | 45 | |||||||||||||||||
| heating power | 6.2 | 7.3 | 9.2 | 13.6 | 16.6 | 16 | 16 | 16 | 16 | |||||||||||||||||
| heating zone | 4 | 4 | 4 | 4 | 4 | 18.5 | 22 | 25 | 28 | |||||||||||||||||
| net height | 2.7 | 3.2 | 4.3 | 5.6 | 6.4 | 8 | 11 | 15 | 19.8 | |||||||||||||||||
| oil tank capacity(t) | 230 | 260 | 360 | 420 | 420 | 440 | 560 | 820 | 850 | |||||||||||||||||
| international designation(l) | 700-230 | 950-280 | 1300-410 | 1600-785 | 2000-1060 | 2400-1390 | 3000-1750 | 3800-2150 | 4800-2710 |
