Non-Negative Pressure Water Supply System in a Building

Summarize:1. High pressure electric water pump has the advantages of energy conversation, small floor space, easy installation, stable performance, etc.2. It gracefully satisfies the needs of water supply in high building, deep well mining or fire-fi

Technical Feature

  • 1 Piece
  • Shanghai, China
  • 500PCS/Month
  • L/C, T/T, Western Union
  • >150m
  • >400 L/min
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Model NO.
GDL
Power
Electric
Start Up
Electric Pump
Application
Water Supply
Media
Water Pump
Theory
Centrifugal Pump
Package
Plywood Case
Size
50~300mm
Color
Any
Fuel
Diesel
Pressure
High Pressure
Trademark
YONJOU
Transport Package
Plywood Case
Specification
standard
Origin
China
HS Code
841311000

DETAIL DESCRIPTION


Non-Negative Pressure Water Supply System in a Building
Summarize:

1. High pressure electric water pump has the advantages of energy conversation, small floor space, easy installation, stable performance, etc.

2. It gracefully satisfies the needs of water supply in high building, deep well mining or fire-fighting equipment, farm irrigation, etc.

3. It's an ideal pump for the delivery of cold or hot water, or fluid similar to water.

4. The high pressure water pump is with higher head (discharge pressure) than regular single stage one.

5. Widely used in energy industry, metallurgy, water processing, chemical industry, spinning industry, papermaking, restaurant, hotels, bathroom, etc.





Product details:

Working Principle:Centrifugal, Multi-stage
Main applications:  Water
Driver:Electric motor
Power Specs:220/380/415V 3phase, 110/220/240v 1phase; 50hz/60hz
Max.permissible fluid temperature:80°C(176°F)
Type of connection:Flange
Installation position:Vertical
Casing material:stainless steel
Shaft seal type: Mechanical seal, packing seal
Free passage:0.1 mm
Maximum drive rating: 90KW(120HP)
Maximum caliber:  150mm(6inch)
Flow rate range: 1.4-194m3/h(6.2-853.6US.GPM)
Maximum head:200m(656ft)





Performance Data:

ModelCapcacityHeadPowerDiameter
m 3 /hmKWmm
25GDL2-12× 32361.125
25GDL2-12× 42481.125
25GDL2-12× 52601.525
25GDL2-12× 62721.525
25GDL2-12× 72842.225
25GDL2-12× 82962.225
25GDL2-12× 921082.225
25GDL2-12× 102120325
25GDL2-12× 112132325
25GDL2-12× 122144325
40GDL6-12× 36361.540
40GDL6-12× 46482.240
40GDL6-12× 56602.240
40GDL6-12× 6672340
40GDL6-12× 7684340
40GDL6-12× 8696440
40GDL6-12× 96108440
40GDL6-12× 106120440
40GDL6-12× 1161325.540
40GDL6-12× 1261445.540
50GDL12-15× 212302.250
50GDL12-15× 31245350
50GDL12-15× 41260550
50GDL12-15× 512755.450
50GDL12-15× 612905.550
50GDL12-15× 7121057.550
50GDL12-15× 8121207.550
50GDL12-15× 9121351150
50GDL12-15× 10121501150
65GDL24-12× 22424365
65GDL24-12× 32436465
65GDL24-12× 424485.565
65GDL24-12× 524607.565
65GDL24-12× 624727.565
65GDL24-12× 724841165
65GDL24-12× 824961165
65GDL24-12× 9241081565
65GDL24-12× 10241201565
80GDL54-14× 254287.580
80GDL54-14× 354401180
80GDL54-14× 454561580
80GDL54-14× 5547018.580
80GDL54-14× 6548418.580
80GDL54-14× 754982280
100GDL72-16× 2723211100
100GDL72-16× 3724815100
100GDL72-16× 4726418.5100
100GDL72-16× 5728022100
100GDL72-16× 6729630100
100GDL72-16× 77211230100




Non-Negative Pressure Water Supply System in a Building
Non-Negative Pressure Water Supply System in a Building


Company Information:
Zhejiang Yonjou Technology Co., Ltd is one of the leading manufacturers and exporters in the field of industry pumps with manufacturing facilities in mainland China. We are specialized in oil pump, diaphragm pump, diesel engine pump, centrifugal pump, screw pump, chemical pump etc.
