Booster Pump System

B603S complete set intelligent constant pressure water supply equipment(3 pumps, maxmum can be 7 pumps)

Characteristics:

. Smooth, quiet operation
. Choice of pressure settings
. Built-in pumping system protection
With a constant pressure system, you don't have to schedule your day around your water usage. BEDFORD constant pressure controllers vastly improve your home water system. Using variable speed technology, BEDFORD continuously monitor water demand and adjust the speed of your pump to provide the water you need without pressure fluctuations. Available in a wide variety of ratings, these systems also provide:
. Vertical Pump Constant Pressure Variable Water Supply Equipment

Power range:
Single phase 220V: 0.37kw~7.5kw
Three phase 220V: 0.75kw~7.5kw
Three phase 380V: 0.75kw~7.5kw

Four sensors are selectable:
. Pressure transmitter 4~20mA
. Transmissible pressure gauge
. Electric contact pressure gauge
. Pressure switch

Applications:
Industiral and agricultural production, high and low-rise residences, villas, schools, hospitals, large community-based, air-source heat pump hot and cold water systems, water treatment, water supply systems, such as energy-efficient building on various occasions
