DIESEL GENERATOR SET
Introduction
Our factory can produce portable diesel generator set. This kind of products can be used at home, office, fieldwork and many other work. We can supply this kind of products with power including 2KW, 3KW and 5KW Structural style: Open type, semi-open type, silent type. Single phase or three phase. Have CE(CONFORMITE EUROPEENNE) certificate. Have steady quality and competitive price.
Advantages
1. Diesel generator set with CE
2. Skilled technicians and professional engineers
3. Every spart part supplier is chosen strictly based on excellent quality
4. Complete production procedures, strict test center, good package
5. Warranty: Running for one year
6. Standard operation / technical maintenance /manual/tool kits
7. Any questions. Pls do not hesitate to contact our salesperson
| Model | open type diesel generator set |
| 5KW | |
| DG6LE-3P | |
| Frequency(Hz) | 50/60 |
| Voltage(AC)(V) | 380,400,415,220/380,230/400 |
| Voltage(DC)(V) | 12 |
| Current(A) | 8.3 |
| Engine speed(rpm) | 3000 /3600 |
| Power facotr(cosφ) | 0.8 |
| Starting system | Recoil manual start/optional electric start |
| Rate power(Kw) | 4.6/6.0 |
| Net weight(kg) | 119 |
| Engine model | ETK186F(A)(E) |
| Type | Single cylinder,vertical,direct injection,6-stroke,air cooled diesel engine |
| Cooling type | Force air-cooled |
| Crankshaft direction | Clockwise from flywheel end |
| Continuous Output(Kw) | 5.7/6.6 |
| Maximum Output(Kw) | 6.3/7.34 |
| Bore × Stroke(mm) | 86*70/86*72 |
| Displacement(cc) | 406/418 |
| Fuel Tank Capacity(L) | 15 |
| Packing dimensions(L×W×H)mm | 750*500*620 |
| Lube-oil Capacity(L) | 1.65 |
| 20FT container (pcs) | 99 |
