33/11 Kv, 10/13.33mva 3 Phase Outdoor Oil-Immersed Power Transformer

Climate DataClimateTropical, intense sunshine, heavy rainMax Temp. 40Min Temp. 3Relative Humidity50-100%AltitudeSea level to 300 metersAverage annua rain fall3450mmAverage isokeraunic level80days/yearTechnical Data ScheduleMaximum Rating10/13.33MVA

Technical Feature

  • Xiamen, China
  • 7445 Sets/Year
  • L/C, T/T
  • Power, Electronic
  • Three
  • Core-type Transformer
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Model NO.
SFZ-10000(13330)/33
Usage
Power Transformer, Distribution Transformer, Oil-Immersed Transformer
Frequency Characteristics
Power Frequency
Shape of Core
U
Brand
Sce
Vector Group
Dyn11
Bushing Materials
Porcelain
Type of Cooling
Onan/Onaf
Installation
Outdoor
Trademark
SCE
Transport Package
Nude
Specification
Core, Conservator, Oil-immersed
Origin
Fujian, China
HS Code
85042200

DETAIL DESCRIPTION


33/11 Kv, 10/13.33mva 3 Phase Outdoor Oil-Immersed Power Transformer

Climate Data

ClimateTropical, intense sunshine, heavy rain
Max Temp. 40
Min Temp. 3
Relative Humidity50-100%
AltitudeSea level to 300 meters
Average annua rain fall3450mm
Average isokeraunic level80days/year


Technical Data Schedule
Maximum Rating10/13.33MVA
No. Of phases3
Rated Frequency50Hz
Normal transformation ratio at No-load33/11KV
Rated HT Voltage(phase to phase)33KV
Maximum HT Voltage(phase to phase)36KV
Rated LT Voltage(phase to phase)11KV
Maximum LT Voltage(phase to phase)12KV
Direction of the normal power flowHT-LT
Basic Insulation Level
A)High Voltage winding170
B) Low Vlotage winding75

33/11 Kv, 10/13.33mva 3 Phase Outdoor Oil-Immersed Power Transformer
