| Specificaton/Model | SJN-3-500 | SJN-3-1000 | SJN-3-1500 | SJN-3-2000 | SJN-3-5000 | SJN-3-8000 |
| Evaporation capaicity(kg/h) | 500 | 1000 | 1500 | 2000 | 5000 | 8000 |
| Steam consumption(kg/h) | 200 | 350 | 500 | 650 | 1500 | 2200 |
| Cycle water consumption(T/h) | 5 | 10 | 13 | 15 | 25 | 40 |
| Evaporation temperature(ºC) First effect | 85 | |||||
| Second effect | 75 | |||||
| Third effect | 65 | |||||
| Vacuum degree(Mpa) First effect | -0.04 | |||||
| Second effect | -0.06 | |||||
| Third effect | -0.08 | |||||
| Steam pressure(Mpa) | 0.1-0.25 | |||||
| Concentration proportion | 1.25-1.4 | |||||
| Length | 5000 | 6500 | 7000 | 7500 | 8000 | 9000 |
| Dimension(mm) Width | 1300 | 1500 | 1700 | 2000 | 2000 | 2500 |
| Height | 3000 | 3500 | 3700 | 4000 | 4500 | 5000 |
Features:
(1) Low evaporation consumption, 1Kg steam can evaporate 3.5Kg water.
(2) Low evaporation temperature. Part of twice steam can be inhaled into single-effect heater through spray type hot pressure pump. The high quality evaporation can be fully used and the evaporation temperature is low.
(3) Large concentration ratio with downward film type evaporation, which can make material liquid with viscosity be so easy to flow and evaporate, Hard to agglomerate with short concentration time. The concentration ratio can reach 1:5.
(4) The equipment can realize automatic production, intellectual system, which is conformity with GMP standard.
Application
The Falling film evaporator is applicable for dairy products, pharmacy, glucose, starch, chemical industry, xylose, citric acid, ammonium sulfate, biological engineering, environment engineering and waste liquid recovery and treatment etc.
