DXD-KL1200 Full automatic pouch packing production line with cartoning machine
SUMMARY
The packaging production line is mainly composed of DXDO-K1200E granule automatic packaging machine, small pouch sorting conveyor, electronic weighing machine, SYZ-120 cartoning machine, detection and pickup, online dynamic weighing removing. In order to control the precision and easy to adjust, the main parts adopt servo motor control.
Suitable for four side sealing sachet automatic connect carton packing.It applies PLC to control, photoelectric to monitor, and servo engine to drive full intelligence machine. Automatic feeding, measurement, bag making, baiting, sealing, printing batch number, vertical slicing, make easy-tearing opening, slicing, fetching bag, arranging, weighing, folding bag, removing discarded, material delivery, folding instructions, box forming, opening, material packing, printing batch number for box, sealing, removing products without instruction, etc. are all completed once, which meet the GMP production requirements, effectively save labor costs and production costs, according to the actual requirements of customers to change design.
Usage:
Suitable for packing loose, non sticky granule material in the pharmacy, food, daily chemical and other industries, automatic packing into sachet with measurement requirement, then automatic with carton packing. Such as Chinese medicine infusion, coffee etc. Crystalline materials as monosodium glutamate, white sugar, salt etc. Tiny pellet materials as Chinese patent drug, Proprietary Chinese medicine, desiccant, silica gel etc.
Main technological parameter :
workshop photos:
The packaging production line is mainly composed of DXDO-K1200E granule automatic packaging machine, small pouch sorting conveyor, electronic weighing machine, SYZ-120 cartoning machine, detection and pickup, online dynamic weighing removing. In order to control the precision and easy to adjust, the main parts adopt servo motor control.
Suitable for four side sealing sachet automatic connect carton packing.It applies PLC to control, photoelectric to monitor, and servo engine to drive full intelligence machine. Automatic feeding, measurement, bag making, baiting, sealing, printing batch number, vertical slicing, make easy-tearing opening, slicing, fetching bag, arranging, weighing, folding bag, removing discarded, material delivery, folding instructions, box forming, opening, material packing, printing batch number for box, sealing, removing products without instruction, etc. are all completed once, which meet the GMP production requirements, effectively save labor costs and production costs, according to the actual requirements of customers to change design.
Usage:
Suitable for packing loose, non sticky granule material in the pharmacy, food, daily chemical and other industries, automatic packing into sachet with measurement requirement, then automatic with carton packing. Such as Chinese medicine infusion, coffee etc. Crystalline materials as monosodium glutamate, white sugar, salt etc. Tiny pellet materials as Chinese patent drug, Proprietary Chinese medicine, desiccant, silica gel etc.
Main technological parameter :
| ITEM | DXDO-K1200 |
| Bag length | 50-150mm(L) (adjustable) |
| Bag width | 40-105mm(W) |
| Packing speed | 40-80bags/min depend on pouch size and material |
| Measuring range | 0.5-60ml/pouch |
| Cutting fashion | Flat cutting |
| Sealing fashion | 4 side sealing |
| Applicable film | PET/AL/PE PET/PE NY/AL/PE NY/PE |
| Max width of film roll | 1200mm |
| Max film roll diameter | Φ300mm |
| Film roll core diameter | Φ75 mm |
| Power voltage | 380V/ 3 phase 4 wires 50HZ |
| Power | 15KW |
| Package size | (L)2300mm×(W)2100mm×(H)1900mm |
| G.W | 1500KG |
| Package size | (L)2200mm×(W)1800mm×(H)2200mm |
| ITEM | SYZ-120 | |
| Encasing speed | 30-100Cartons/min | |
| Sachet quantity | 1-12bags(base on sachet or pouch size) | |
| Carton | Quality requirement | 250-350g/ base on carton size |
| Dimension range(LXWXH) | (70-180)mm X(35-85)mmX(14-50)mm | |
| Instruction | Quality requirement | 60-70g/ |
| Unfolded size range | (80-250)mm X(90-170)mm | |
| Fold range | fold 1-4 times | |
| Compressed air | Working pressure | >=0.6Mpa260-300L/Min220V 50HZ |
| Air consumption | 260-300L/Min | |
| Power supply | 220V 50HZ | |
| Motor power | 2.2KW | |
| Machine dimension(LXWXH) | 4200X1050X1600mm | |
| Machine weight | 1600Kgs |
