Factory Best Sell Automatic Pretreatment Filters RO Water Purification Plant

2015 Factory best sell Automatic pretreatment filters ro water purification plant(KYRO-6000)RO water treatment system plant can treat tap water, well water, brackish water and sea water. This water treatment equipment can

Technical Feature

  • Guangzhou, China
  • 80 Sets /Month
  • L/C, T/T, Western Union, 1 Year gaurantee
  • Reverse Osmosis
  • Environmental Protection, Chemical Industry, Water Treatment
  • Electric power
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Model NO.
KYRO-6000
Electricity Consume
9.5kw/H
Pre-Treatment Dimension
u03c61000u00d71950 FRP
Desalination Rate
More Than 97%
Power
220V/380V, 3 Phase/1 Phase, 50Hz/60Hz
Option 1
Water Softener
Option 2
UV Sterilizer
Option 3
Ozone Generator
Trademark
kaiyuan
Transport Package
Wooden Case
Specification
CE/SGS/ISO9001
Origin
Guangdong, Guangzhou
HS Code
8421299090

DETAIL DESCRIPTION

2015 Factory best sell Automatic pretreatment filters ro water purification plant(KYRO-6000)


RO water treatment system plant can treat tap water, well water, brackish water and sea water. This water treatment equipment can be used for drinking water, bottled water and industrial. Water treatment machine using the advanced skills of reverse osmosis to purifying water. The RO membrane of this water filter is USA DOW, this is the best RO membrane brand.

A. Description:
RO water treatment, the raw water is tap water, first goes by pre-treatment, then by RO treatment. Through those treatments, can remove dissolving salt 99% and harmful materials, like particle, colloid, organic impurities, heavy metal ions, bacteria, viruses and heat source, etc. The system salt rejection rate gets 96-98%, outlet water conductivity gets ≤ 10μ S/cm² .

B. Process:
Raw water+ raw water tank+ raw water pump+ sand filter + carbon filter+ water softener ( optional) + security filter +high pressure pump+ reverse osmosis+ pure water tank + UV sterilizer (ozone generation)+ precision filter + water supply points

C. Parameters:
1. Capacity: 6000L/H
2. Rated power: 9.5Kw/H
3. Voltage: 220V/50Hz, 380V/50Hz
4. Desalting rate: 97-98%
5. Water recovery rate: 50-70%
6. Conductivity of raw water: ≤ 400μ S
7. Conductivity of pure water: ≤ 10μ S
8. With water softener

Detailed specification
1) Adopts imported RO membrane from America, which can remove 99.7% inorganic salt, heavy metal ion and completely get rid of colloid, microbiology organic materials, germ, protozoa, pathogens, bacteria, inorganic chemical and so on.
2) No need to add any chemicals, stable pure water quality, and no pollution drained, low produce cost.
3) Equipped with pretreatment system, such as active carbon absorption filter and PP sediment filter.
4) 304 stainless steel rack and pipe accessories connection.
5) Equipped with auto pressure protection system and on -line monitor.
6) Automatically and manually wash RO membrane. Also the design of washing the RO membrane is by chemical solution (citric acid or sodium hydroxide optional).
7) The lifespan of the whole system is long, operation simple, the applicability is strong

Picture of machine:


  4T/H Reverse Osmosis System :


  20T/H Reverse Osmosis System :



 we also have bellowing smaller Reverse Osmosis System :

  1T/H Reverse Osmosis System :



Kai yuan Advantage :

Kai yuan mainly specialized in water treatment industry with its own factory for many years, will always provide the good quality and best price for the customers as below :

1).RO Membranes : from USA brand, it is USA DOW .

2).High pressure pump: CNP pump (the best pump in China)

3)Engineers : work in this industry for 10 years ,can design the best solution and
            provide technical guideline .

4)QC Team :we have professional QC team ,can guarantee stable quality for
            OEM production service.

5)Installation : Easy operation with Video ,or we could arrange experienced
             engineer to local place for installation .

Technical specification for 6000L/H
ModelKYRO-6000
Production capacity6000 L/Hr
Power9.5kw
Power supplyAC 380V 50Hz
Reverse osmosis (RO)membraneMembrane  BW30-400  6pcs USA DOW
Membrane housing4040 stainless steel
Raw water pump CHL8-40
Quartz sand filter, activated Carbon filterφ1000×1950 FRP   2pcs
Security filter30 "× 5μm ,9core
High pressure pumpCDL12-12/7.5KW     1 set Nanfang
Activated carbon 375kg
Quartz sand 1300kg
Size (mm)main machine:  3200X900X1800mm
filtering tank:Φ1000×1950mm

Our company is professionally in producing reverse osmosis (RO) water machine, pure water treatment plant, purified ro water filter, industrial water, well water treatment unit, softened water equipments, underground water treatment equipments, iron manganese removal equipments, laboratory deionized water equipments, deionized water equipments, direct drinking water equipments, domestic drinking water equipments, EDI high purity water, swimming pool water purifying equipments, river, seawater desalination equipments, ultrafiltration(UF) equipments, electroplate water treatment equipments, ion exchange equipments- Mixed bed, water softener, all kinds of water treatment consumable(need replaced parts) materials(PP sediment cartridge, RO membranes), accessories, can be customized various kinds of model as your requirements.



FAQ

1.What is the Guarantee and after sale-service Kai yuan company can supply ?
 it is one year guarantee ( except for Artificially damaged)  Any problems with the accessories,like valves , pumps etc. within 1 year , we could delivery to you for free .

2.Does the machine/equipment difficult to install ?

Kai yuan factory already connect/adjust well for the machine before delivery ,and we will Provide the specific entire system"User Manual",if need can take Video for how to operate machine. .

3.Does Kai yuan will help customer install the machine in their country ?
In additional , Kai yuan can also send their engineers to customer place to install this equipment and train staff, but the buyer should pay for the relevant cost for our workers.

4.What is the packing of this machine ? Is it suitable for shipment?
Machine will be packed by standard wooden case. It is suitable for shipment. After you receive machine, you open wooden case to pick out of machine is ok .

5.what is the payment for the orders customer make ?
       After we confirmed order, will send you contract sales/PI with our company bank information. You can transfer money to our company bank account by T/T.,Western Union or do L/C if it is accepted by both of us .

6. What is requirement information i need to provide for achieve the suitable ro machine/other relevant products i want ?
    It is kindly that you could provide us a  raw water analysis /water test report .

7.Why we need to choose Kai yuan from so many suppliers in China?
    Guangzhou Kaiyuan Water Treatment Equipment Co.,ltd products are sold well not only in domestic, but also in UAE, Saudi Arabia, South Africa, Kazakhstan, Sri Lanka, Vietnam, Haiti, Spain, Australia, Nigeria, Uganda, New Caledonia, Ecuador, Sudan, Guatemala, Somalia, Cameroon, Malaysia ,Ghana, Lebanon etc. Countries.
  we have bellowing  :

we have a big bright factory in GZ city , bai yun distric, which is near to GZ Bai yun air port .
QC Team :we have professional QC team ,can guarantee stable quality for OEM production service.
Installation : Easy operation with Video ,or we could arrange experienced
             engineer to local place for installation .

     4.Packing :Standard wooden packing will reinforce protect machine.

     5.Competitive price :we are confident with our competitive price in the
                 international global market.



Note


 Any more details about our products , pls feel free to contact with us as below , we will write you back for   RO water treatment within 24 hours .
