Smart Differential Pressure Transmitter with Digital Output

Qualified Chinese original manufacturer that exported  pressure transmitters to overseas markets (EURO,AMERICA,ASIA)    more than 200,000+ sets.Features:Enough Experience on local applications for overseas marketsRP1001 Pressure transmitterMeet yo

Technical Feature

  • Shanghai, China
  • 100000 Pieces/Year
  • L/C, T/T, D/P, Western Union, Paypal, Money Gram
  • Intelligent Pressure Transmitter
  • Monocrystalline Silicon
  • Steam Liquid Gas
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$99~999

PRIMARY PARAMETERS

Model NO.
RP1001
Certification
Ce Atex Nepsi
Customized
Customized
Accuracy
0.05%
Stability
u00b10.1% /3 Years
Output Signal
Two-Wired 4~20mA/Hart
Certificates
Atex Ce Nepsi
Measuring Type
Liquid,Gas,Wind,Steam
Measuring Range
0~40MPa
Measurement Medium
Gas,Steam,Liquid
Isolating Diaphragm
316L/Hastelloy C/Gold Plated on 316L
Fill Fluid
Silicone Oil
Process Connector Gasket
NBR/FKM/PTFE
Trademark
RKS
Transport Package
Cartoon
Specification
3.3KG
Origin
China
HS Code
9026201090

DETAIL DESCRIPTION

Qualified Chinese original manufacturer that exported  pressure transmitters to overseas markets (EURO,AMERICA,ASIA)    more than 200,000+ sets.

Features:
Enough Experience on local applications for overseas markets

RP1001 Pressure transmitterMeet your toughest environmental conditions with -45ºC working LED display (Option), Customerized color of Housing,  Special manual with local language, technical support for OEM,ODM coopertion,etc.

Specifications:

Measurement TypeDifferential, Gage, Absolute, Level, Flow
Output4-20mA
Reference Accuracy

±0.05% of span (0.075% Option)

Long Term Stability+ 0.1% of URL for 3 years
Processing Temperature -40 to 85ºC
Rangedown

100:1



Measuring

range



B

0-200Pa~6kPa(0-20~600 mmH2O)/(0-2~60mbar)



C

0-400Pa~40kPa(0-40~4000 mmH2O)/(0-20~400mbar)



D

0-2.5kPa~250kPa(0-0.25~25 mH2O)/(0-25~2500mbar)



F

0-30kPa~3MPa(0-3~300 mH2O)/ (0-0.3~30bar)
