In the electrical wiring of buildings, a cable tray system is used to support insulated electric
cables used for power distribution and communication. Cable trays are used as an alternative to open wiring or electrical conduit systems, and are commonly used for cable management in
commercial and industrial construction.
Images
Application:
It generally applies to large power cables laid, especially suitable for high and low voltage power cables.
Material:
Common cable trays are made of galvanized steel, aluminum, or glass-fiber reinforced plastic.
The material for a given application is chosen based on where it will be used.
Supporting arm types:
cables used for power distribution and communication. Cable trays are used as an alternative to open wiring or electrical conduit systems, and are commonly used for cable management in
commercial and industrial construction.
| Model | Spec(A×B) | Weight(kg) | |
| HT-C-01 | -1 | 50×25 | 7.95 |
| -2 | 100×50 | 14.7 | |
| -3 | 150×75 | 20.3 | |
| -4 | 200×100 | 36.41 | |
| -5 | 250×125 | 40.81 | |
| -6 | 300×150 | 47.47 | |
| -7 | 400×200 | 79.2 | |
| -8 | 500×200 | 90.01 | |
| -9 | 600×200 | 101.68 | |
| -10 | 800×200 | 125.13 | |
| Remark:1.h=60,100 is single row connect hole, h=150 is double row connect holes. 2.The horizontal elbow is calculated 0.8 times of the weight per meter. 3.The horizontal triple is calculated 1.2 times of the weight per meter. 4.Reference by JB/T10216-2000 |
Images
Application:
It generally applies to large power cables laid, especially suitable for high and low voltage power cables.
Material:
Common cable trays are made of galvanized steel, aluminum, or glass-fiber reinforced plastic.
The material for a given application is chosen based on where it will be used.
Supporting arm types:
| Model | L(mm) | Weight(kg) | Remark |
| TB-01A-10 | 140 | 1.51 | Bolt and pressing board are inlcuded |
| TB-01A-15 | 190 | 1.67 | |
| TB-01A-20 | 240 | 1.83 | |
| TB-01A-25 | 290 | 1.98 | |
| TB-01A-30 | 340 | 2.14 | |
| TB-01A-40 | 440 | 2.48 | |
| TB-01A-50 | 540 | 2.99 | |
| TB-01A-60 | 640 | 5.17 | |
| TB-01A-80 | 840 | 7.03 | |
| TB-01A-100 | 1040 | 8.95 |
| Model | L(mm) | Weight(kg) | Remark |
| TB-01A-10 | 140 | 1.51 | Bolt and pressing board are inlcuded |
| TB-01A-15 | 190 | 1.67 | |
| TB-01A-20 | 240 | 1.83 | |
| TB-01A-25 | 290 | 1.98 | |
| TB-01A-30 | 340 | 2.14 | |
| TB-01A-40 | 440 | 2.48 | |
| TB-01A-50 | 540 | 2.99 | |
| TB-01A-60 | 640 | 5.17 | |
| TB-01A-80 | 840 | 7.03 | |
| TB-01A-100 | 1040 | 8.95 |
| Model | L(mm) | Weight(kg) | Remark |
| TB-03-10 | 140 | 1.14 | Bolt and pressing board are inlcuded |
| TB-03-15 | 190 | 1.21 | |
| TB-03-20 | 240 | 1.29 | |
| TB-03-25 | 290 | 1.71 | |
| TB-03-30 | 340 | 1.76 | |
| TB-03-40 | 440 | 2.34 | |
| TB-03-50 | 540 | 2.83 | |
| TB-03-60 | 640 | 3.41 | |
| TB-03-80 | 840 | 4.29 | |
| TB-03-100 | 1040 | 5.2 |
| Model | L(mm) | Weight(kg) | Remark |
| TB-04-10 | 140 | 0.85 | Bolt and pressing board are inlcuded |
| TB-04-15 | 190 | 1.06 | |
| TB-04-20 | 240 | 1.24 | |
| TB-04-25 | 290 | 1.28 | |
| TB-04-30 | 340 | 1.33 | |
| TB-04-40 | 440 | 1.58 | |
| TB-04-50 | 540 | 1.78 | |
| TB-04-60 | 640 | 2.52 | |
| TB-04-80 | 840 | 2.75 | |
| TB-04-100 | 1040 | 3.14 |
