Introduction:
V The instrument is designed and made as per T0625 in JTJ052.
V It is suitable to determine absolute viscosity of Newton liquids and apparent viscosity of non-Newton liquids.
V It can be widely used to determine viscosity of asphalt, hot melt adhesive, paraffin, high polymer, and other liquids.
V It is sensitive, reliable, convenient, beautiful, and it only needs little sample.
Characteristics:
V Designed and made as per T0625-2011 in JTG. E20.
V LCD display, with blue light as background, display: Viscosity, spindle number, rational speed, temperature, torque(per cent), shearing stress, shearing rate, and the measurement range.
V Preset the rotational speed as the scale, and stepless regulation, to satisfy the continuous test.
V Spindle is made of SS, anti-corrosion, and convenient for user.
V Optional: Heating stove up to 300° C and controller;
V Optional: Application software.
Technical parameters:
V Measurement range: 100mPas~200000mPas;
V Spindles: Four spindles, No. 21, 27, 28 and 29.
V Spindle speed: 5, 10, 20 and 50 RPM;
V Measurement error: ± 1% (FS);
V Measurement mode: Manual;
V Temperature controlling range: Room temperature~200° C;
V Temperature controlling accuracy: ± 0.1° C;
V Cubage of sample chamber: 20 ml;
V Power supply: AC 220V± 10%, 50 Hz;
V Ambient temperature: 5° C~35° C;
V Relative humidity: Not more than 80%;
V The instrument is designed and made as per T0625 in JTJ052.
V It is suitable to determine absolute viscosity of Newton liquids and apparent viscosity of non-Newton liquids.
V It can be widely used to determine viscosity of asphalt, hot melt adhesive, paraffin, high polymer, and other liquids.
V It is sensitive, reliable, convenient, beautiful, and it only needs little sample.
Characteristics:
V Designed and made as per T0625-2011 in JTG. E20.
V LCD display, with blue light as background, display: Viscosity, spindle number, rational speed, temperature, torque(per cent), shearing stress, shearing rate, and the measurement range.
V Preset the rotational speed as the scale, and stepless regulation, to satisfy the continuous test.
V Spindle is made of SS, anti-corrosion, and convenient for user.
V Optional: Heating stove up to 300° C and controller;
V Optional: Application software.
Technical parameters:
V Measurement range: 100mPas~200000mPas;
V Spindles: Four spindles, No. 21, 27, 28 and 29.
V Spindle speed: 5, 10, 20 and 50 RPM;
V Measurement error: ± 1% (FS);
V Measurement mode: Manual;
V Temperature controlling range: Room temperature~200° C;
V Temperature controlling accuracy: ± 0.1° C;
V Cubage of sample chamber: 20 ml;
V Power supply: AC 220V± 10%, 50 Hz;
V Ambient temperature: 5° C~35° C;
V Relative humidity: Not more than 80%;
| Model | GDJ-1C | GDJ-1D | GDJ-1F |
| R ange (mPa.s) | 100~200,000 | 100~2,000,000 | 25~10,000,000 |
| Speed(RPM) | 5/10/20/50 | 0.5/1/2/5/10/20/50 | 0.1-100 |
| Spindle | 21 # , 27 # , 28 # , 29 # | ||
| A ccuracy | ±1% | ||
| Controlling temperature | Room temperature -200°C | ||
| Resolution | ±0.1°C | ||
| Repeatability | ±0.5% | ||
| Optional parts | 300°C(heater) |
