Steam Generator Coal Fired Steam Boiler Steam Generator Turbine
Features
1, The usage of high-performance heat transfer components - threaded pipe, with a reasonable gas flow rate, the boiler thermal efficiency is higher 6-8 percentage points than the state high professional standards.
2,Arch tube plate, thread to make pot pipe from the quasi-rigid body shell variable based elastomer with the airfoil stack, completely avoid the defects that traditional high-temperature pyrotechnic tube boiler tube plate cracking.
3, Reasonable and unique water circulation loop backwater ejector device (hot water boiler), improved the increased water velocity, to avoid the water-wall tube break.
4, The usage of inertial separation of dust furnace, supplemented by high-performance multi-collector, so that the concentration of dust emission boiler to meet the demand for a class.
Our Main Product scope:
1. WNS series Horizontal oil/gas fired boilers (0.5-30T/H, 0.7-14MW)
2. SZS series Horizontal Oil/gas fired boiler (4- 35T/H )
3. LHS series Vertical Oil/gas fired boiler (0.1-2 T/H, 0.06-0.7MW )
4. DZL new type water fire tube boilers (1-35T/H, 0.7-29MW)
5. SZL series water tube biomass boilers (4-35T/H, 1.4-29MW)
6. SHX boiler boiler ( 10--35 T/H)
7. CFB Circulating Fluidized Bed boiler ( 35T--130 T
)
Boiler Aplication:
Steam boiler can be used for product manufacturing process in textile factory, printing and dying, papermaking, rubber industrial , plastic industrial , chemical, pharmaceutical, etc.; and Hot water boiler for heating room, bath, air conditional, and daily life water in the factories, departments, hotels, schools, restaurants, services industries etc.
Boiler technical data:
| coal fired steam boiler | ||||||||||||
| Item/Type | DZL1-0.7-AII DZL1-1.0-AII DZL1-1.25-AII | DZL2-0.7-AII DZL2-1.0-AII DZL2-1.25-AII | DZL3-0.7-AII DZL3-1.25-AII | DZL4-1.25-AII | DZL6-1.25-AII | DZL8-1.25-AII | DZL10-1.25-AII | DZL15-1.25-AII | DZL20--1.25-AII | DZL25-1.25-AII DZL25-1.6-AII | DZL30-1.25-AII DZL30-1.6-AII | |
| Rated capacity t/h | 1 | 2 | 3 | 4 | 6 | 8 | 10 | 15 | 20 | 26 | 30 | |
| Rated steam pressure Mpa | 0.7/1.0/1.25 | 0.7/1.0/1.25 | 0.7/1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25 | 1.25/1.6 | 1.25/1.6 | |
| Rated Steam Temperature °C | 170/184/194 | 170/184/194 | 170/194 | 194 | 194 | 194 | 194 | 194 | 194 | 194/204 | 194/204 | |
| Feed water temperature °C | 20 | 20 | 20 | 20 | 20 | 60 | 105 | 105 | 105 | 105 | 105 | |
| Heated area m2 | Radiation convection | 4.68/16.1 | 6.2/39.5 | 8.2/45.3 | 10.06/73.53 | 15.2/92.38 | 22.3/159.5 | 19.5/207.6 | 33/290 | 34.36/408.51 | 99.21/457.79 | 44.5/628.6 |
| Boiler Thermal efficiency % | 79 | 79.07 | 82 | 80 | 81 | 80.5 | 80.6 | 80.6 | 81 | 81.38 | 81.76 | |
| Fuel Consumption kg/h | 167 | 330 | 49.8 | 662 | 998 | 1325 | 1655 | 2480 | 3290 | 3551 | 4230 | |
| Effictive area of grate m2 | 1.8 | 3.04 | 3.34 | 5.14 | 9.36 | 10.9 | 12 | 17 | 22.56 | 24.67 | 26.88 | |
| Max. transport size | L (mm) | 4876 | 5290 | 5360 | 6237 | 6300 | 7486 | 7600 | 7350 | 7810 | 8478 | 9000 |
| W (mm) | 1800 | 2240 | 2240 | 2660 | 3150 | 3200 | 3200 | 3370 | 3370 | 2600 | 2600 | |
| H (mm) | 2820 | 3208 | 3208 | 3520 | 3938 | 3350 | 3660 | 3510 | 3500 | 2740 | 2850 | |
| Weight of largest parts of boiler transporting (T) | 13.3/13.5/13.7 | 18.5/18.8/18.8 | 20.8/21 | 27 | 35 | 31 | 44 | 22 | 25 | 25.5 | 30 |
Our Spirit:Supply Reliable & High Efficient Heating System.
1, More Than 600 Sets Of Boilers (5000 T/H) Can Be Produced By Us Per Year. Class A Boiler Manufacturer. Class A1, A2 Pressure Vessel Manufacturer.
2, Each Boiler System Parts Is From First Class Brand All Over The World Or China.
3, Strict Quality Control System. From The Material, Welding, To Finished Boiler Shipment. From Project Establishment, Drawing Design, To Final Audit.
4, We Are The Stable And Long Term Supplier Of Many Top 500 Groups All Over The World. Such As PetroChina, Sinopec, Nestle, Mercedes-Benz, Coca Cola, etc, .
5, Welcome Visit Our Factories And Users.
Class A boiler manufacturer. 600 sets per year of boiler produce capacity. ASME, GB, CE, GOST, AS standard.
After-sale services
1. Assist clients to prepare for the first construction, and also can arrange engineer on-site instruction of installation and commissioning
2. Install and debug the equipment;
3. Train the first-line operators;
4. Examine the equipment;
Factory assurance
1. One year parts warranty
2. Spare parts available at ex-factory price
3. Different voltage available
4. 100% tested before delivery
5. Skid-mounted complete system available 100-- 2000 kg/h.
6. Complete system fixed in container available 100-- 4000 kg/h.
7. Engineer on-site instruction of installation and commissioning available.
High Quality with Mature Design:
1. Quality:
A grade boiler, A1, A2 grade pressure vessel manufacturing company. All products have passed ISO9001:2008 & ASME International Quality Management System Certification, also can provide CE, AS, GOST certification.
2. Management:
In order to ensure the quality, we strictly monitor the comprehensive quality system from raw material procurement & re-testing & process to storage. All the steels and pipes are purchased from developed countries & the well-known large domestic enterprises.
3. Welding:
Welding mainly uses advanced automatic welding, gas protected welding, TIG welding. Drum and other main pressure parts adopt CNC automatic welding, all of the welding 100% passed penetrant inspection.
4. Market:
Asia: Kazakhstan, Uzbekistan, Kyrgyzstan, Tajikistan, Azerbaijan, Singapore, Hongkong, Philippines, Indonesia, Thailand, myanmar, Laos, United Arab Emirates, Saudi Arabia, Palestine, Afghanistan, Bangladesh, Malaysia, Qatar , Lebanon, Armenia, Yemen, Jordan
America: Colombia, Chile, Suriname,Peru, Bolivia, Ecuador
Africa: Sudan, Cameroon, Algeria, Libya, Benin, Nigeria, Egypt, Ghana, Guinea, Mauritius, Kenya, Ethiopia, Cote d'ivoire, Tunisia
Europe: Serbia, Albania
contact information:
If any needs ,pls feel free to contact with me
Qingdao East Power Industry Equipment Co., Ltd
Skype:epboiler1
Add: Hi-technology Industrial Park, Qingdao, Shandong, China
Pictures:
Q: Are you manufacturer?
A: Yes, we are manufacturer. Our factory is in Pingdu Qingdao established in 1993.
Q: Do I get guarantee of products?
A: Yes, every product is 1 year quality warrantee under customer correct using the products.
Q: Do you have any Certificate?
A: Yes. Each of our boiler has China GB certificate. If you need CE ASME or AS, we can help you to get it.
Q: How to buy it?
A: Please contact me by email or online, let me know your factory situation, I will give you some advice which model mostly suitable to you.
Q: What about the delivery?
A: We have shipping agent can choosing the cheapest and fastest delivery. FOB,CIF, C&F or EXW are no problem for us
Q: How can I pay you?
A: T/T, LC is very well used.
Q: What about the production?
A: Produce time is 20~25days for <6Ton boiler, 25~40days for >8Ton boiler.
Q: Could you offer some wear parts?
A: Yes, some chain grate bars, electric equipments in control panel box for example.
Q: What about the maintenance?
A: I will offer you the timely maintenance way sheet after installation of the boiler mainly parts.
China
